Ride-on Brushcutter
CMX1402 / CM1401
Operator's Manual
Read this manual completely before operating or maintaining this machine.
Failure to follow safety precautions could result in serious injury or death.
Keep this manual for future reference by you and by all those who operate
and maintain this machine.
Original Instructions
(in English)
5321 5311 003
5355 5351 005
Advertisement
Table of Contents
Related Manuals for CanyCom Masao CMX1402
Summary of Contents for CanyCom Masao CMX1402
- Page 1 Ride-on Brushcutter CMX1402 / CM1401 Operator's Manual 5321 5311 003 Read this manual completely before operating or maintaining this machine. Failure to follow safety precautions could result in serious injury or death. Keep this manual for future reference by you and by all those who operate and maintain this machine.
- Page 2 90-1 Fukumasu, Yoshii-machi, Ukiha-shi, Fukuoka, Japan 839-1396 Sales Headquarters (International) TEL +81-(0)943-75-2195 FAX +81-(0)943-75-4396 Authorized Dealer All rights reserved. Unauthorized use or reproduction of this material is prohibited.
- Page 3 Notice to Users and Maintenance Personnel Thank you for purchasing this machine. This manual provides information needed for safe and effective use of this machine to those who operate or maintain machine. Make sure to read and understand the manual thoroughly before operating this product.
- Page 4 Notice to Owner • Be sure that everyone who uses this machine, including those who rent or lease this machine, receives a copy of this Operator's Manual and understands the importance of reading and following the information in this manual. Warning Terms Used in this Manual In this manual, the following four warning terms are used to signal the four levels of hazard (or seriousness of possible accidents).
- Page 5 Warranty and After-Sales Service Warranty CHIKUSUI CANYCOM, INC. guarantees this product, based on the terms of warranty. After-Sales Service Consult your local CANYCOM dealer or our company’s sales department regarding service orders or any questions or problems that may arise when using this machine. Please make sure to have the product name, serial number, and the make and type of engine handy at the time of contact.
-
Page 6: Table Of Contents
Contents 1. Safety Safety Labels ........1 Safety Mechanisms . - Page 7 Driving ........23 Starting .
- Page 8 Engine ........55 Engine Oil .
- Page 9 7. Transporting Hauling ........84 Loading and Unloading .
-
Page 10: Safety
• Replace these labels immediately if they have been removed, have fallen off or become illegible. Use the part number, on the label or shown in this manual, to order a replacement label from your CANYCOM representative. (Behind seat back) - Page 11 Safety 5332 5121 000 5347 5109 000 5332 5122 000 5347 5114 000 5332 5128 000 5321 5116 000 5305 5326 000 5332 5127 000 5347 5125 000 X73-20057-60 3667 5063 000 5355M-0101-020E...
-
Page 12: Safety Mechanisms
Safety Safety Mechanisms This product is equipped with the following safety mechanisms. Start Interlock Mechanism Engine can be started only when parking brake is in [ (engaged)] position and cutting rotary clutch in [OFF] position. This is to prevent unintended movement of machine or cutting blade when starting engine. -
Page 13: Safety Precautions
Safety Safety Precautions This section contains safety precautions to follow when operating and maintaining the machine. Read and understand the precautions in this section as well as throughout this manual and follow them when operating or maintaining the machine. Failure to follow safety precautions could result in property damage, serious injury or death to the operator or bystanders. -
Page 14: Preparation
Safety Preparation • Fuel is highly flammable. See Checking and Filling Fuel, page 17, for important safety information on handling fuel. • Always wear protective footwear, long trousers, hardhat, safety glasses and ear protection when operating or servicing the machine. Proper clothing will minimize the chance of injury. -
Page 15: Operation
Safety Operation This machine is intended for cutting grass and bushes. Any other use may pose hazard or cause damage to the machine. The stability of the machine is affected by the speed, rate of steering, terrain and the operator's weight. Always pay close attention to these factors or a loss of control or tip over could occur, resulting in property damage, serious injury or death. - Page 16 Safety • Always travel slowly and use extra caution when operating on unfamiliar terrain. Be alert when traveling on changing terrain. • Never operate on terrain that you are not comfortable with. Avoid terrain that is so rough, slippery or loose that you feel like you could tip over. •...
- Page 17 Safety Driving on a Slope • Never use on a slope steeper than 20 degrees for the AWD (all-wheel-drive) machine, and 15 degrees for the 2WD machine. • Driving on a slope can be dangerous. It can result in a tip over and cause serious injury or death.
- Page 18 Safety Cutting When conducting cutting operation, take the following precautions. • Always follow the proper procedures for cutting as described in this manual. • Shutt off the work site. Post signs to inform of the cutting operation. Close off the site with rope if necessary to keep people, especially children, off the work site.
-
Page 19: Servicing
Safety Servicing • Do not service the machine when the engine is running. If it is absolutely necessary to run the engine while servicing, pay attention to the moving parts. • Do not operate the engine in a confined space where dangerous carbon monoxide fumes can accumulate. -
Page 20: Controls And Components
Controls and Components Name and Function of Controls Fuel Filler Cap Seat Front Cover Tool Box Handrail (Under Front Cover) Head Lamp Rear Fender, Left Side Cover, Left Front Bumper Cutting Blade Shield, Left Front Tire Forward Plastic Bottle Holder Engine Guard Steering Wheel Upper Rear Cover... - Page 21 Controls and Components 5355M-0201-020E -12-...
- Page 22 Controls and Components 1 Main Switch ... . . Main switch is used to start or stop engine. 2 Choke Knob ... . . Choke Knob is used to help start engine by closing choke valve.
- Page 23 Controls and Components 10 Differential Lock Lever ..Differential lock lever is used to lock differential when rear wheels slip. Tilting differential lock lever to [ON] position locks differential. 11 Cutting Height Adjust ..Cutting height adjust lever is used to adjust the cutting Lever height.
-
Page 24: Specifications
Specifications Product Specifications · Use this product properly after understanding its specifications thoroughly. CM1401 CMX1402 Model and Type Machine Mass Mowing Rate 7200 1980 Overall Length Overall Width 1085[1020] Overall Height Wheelbase 1300 Front Tread Rear Ground Clearance Model Robin EX40DS Type Air-cooled 4-cycle single cylinder OHC, Gasoline Cylinder (Bore×Stroke) -
Page 25: Contents Of Tool Bag
Specifications CM1401 CMX1402 Model and Type HST (Continuously Variable) Main Transmission Constant Mesh Auxiliary Transmission Front AGR 4.00-7 (2PR) Tires Rear 17X8.00-8 (4PR) Rack and Pinion Steering Round Steering Wheel Brakes Internally Expanding Cutting Width Cutting Height 0~150 (21 Steps) Blade Type Free Knife &... -
Page 26: Operation
Operation Preparation Pre-start up Inspection • Always perform an inspection before every use. If a problem is found, solve or repair it before use. • Clean the mowing dust before use to avoid fire. • Make sure the cooling air intake is not blocked or clogged. If it is blocked, the engine overheats. -
Page 27: Adjusting Steering Wheel
Operation Open fuel filler cap and fill fuel. Put fuel filler cap back in place and close it Fuel Filelr Cap securely. NOTE • Fuel : Automotive Unleaded Gasoline • Fuel Tank Capacity : 7.0L 5355M-0401-020E Adjusting Steering Wheel • After adjusting steering wheel, try moving steering wheel back and forth and up and down to make sure it is securely locked in its position. - Page 28 Operation Pull out front cover. NOTE • Inside of the front cover is made as tool box. Use this box to store items such as tools or substitute cutting blades. 5347M-0401-110E Remove fixing pin from steering column in Steering Column the front of machine.
-
Page 29: Adjusting Seating Position
Operation Adjusting Seating Position • Beware of pinch points when adjusting seating position. • After adjusting seat, try moving seat back and forth and up and down to make sure it is securely locked in its position. Sliding seat Seat Pull slide lever to the right to slide seat forward or backward. - Page 30 Operation Adjusting Height (Front Part) Height of seat at front can be set in one of two positions. NOTE • Height of seat at front is set at the low position when shipped from the factory. • Seat switch bracket at the back needs to be in the highest position when setting the front in high position.
-
Page 31: Adjusting Drive Pedal
Operation Adjusting Height (Rear Part) Slide seat to the rear-most position. Pull up seat and push safety pin toward inside to hold seat lifted. NOTE • Move seat and to check if the seat is locked securely. • Height at the rear can be adjusted in 4 levels •... -
Page 32: Driving
Operation Driving Starting • Always start and run engine in a well ventilated place. • Always stay on seat when starting engine. Never attempt to start engine away from machine. Run over accident may result. • Do not turn main switch to [ (start)] position when engine is running. - Page 33 Using this machine under such conditions may result in an accident or cause damage to machine. If you need to use this machine above that altitude, contact your CANYCOM representative. Make certain brake pedal is depressed and locked. If it is not, depress brake pedal and pull lock lever to lock it.
- Page 34 Operation Make certain drive lever is in neutral position. Drive Lever Neutral Position NOTE • Drive lever returns to neutral position when brake pedal is fully depressed. 5347M-0402-040E Open fuel cock. Fuel Cock Close Open 5355M-0402-060E Make sure throttle lever is in the [ (slow)] position.
-
Page 35: Driving
Operation Turn key to [ (start)] position to start engine. Release key immediately after engine starts. Key automatically returns to (ON)] position. Push back choke knob to open choke valve. 10. Run engine without load for about 5 minutes to warm up. Main Switch 5332M-0402-070E NOTE... - Page 36 Operation • Do not operate drive pedal and drive lever simultaneously. • Do not turn the key to [ (off)] position while traveling. • Do not operate drive pedal or drive lever when brake is locked with parking brake lock lever. It can wear out brake. M a k e c e r t a i n o f t h e s a f e t y o f y o u r surroundings.
- Page 37 Operation Depress brake pedal to release brake pedal lock. Brake Pedal 5347M-0402-120E Driving with Drive Pedal Depress gradually the forward or reverse side Drive Pedal of drive pedal to move in the corresponding direction. NOTE • Speed can be adjusted continunously by the position of drive pedal.
-
Page 38: Stopping
Operation Stopping • Do not make a sudden stop. Operator may be thrown off, or machine may skid or tip over. • Always park on a firm, level place. Never park on a potentially dangerous place. • Do not park near combustibles. •... -
Page 39: Shifting
Operation Depress brake pedal to stop machine completely. NOTE • When brake pedal is depressed, drive lever returns to neutral position. Brake Pedal 5347M-0402-120E Shifting • Always shift gears firmly. When transmission is not firmly shifted, it may jump out of gear, resulting in loss of control of machine. •... -
Page 40: Shifting Between 2Wd And Awd (Cmx1402)
Operation Shifting Between 2WD and AWD (CMX1402) • Always stop machine to shift between 2WD or AWD (all-wheel-drive) modes. Shifting gears while machine is in motion can damage transmission. • Use 2WD mode under normal condition. • Pay attention to the minimum turning radius in AWD mode. In AWD mode, minimum turning radius is greater than that in 2WD mode. -
Page 41: Locking Differential
Operation Locking Differential Differential can be locked to minimize slipping on slippery surface. • Always stop machine to operate differential lock lever. Operating differential lock lever while machine is in motion can damage differential. • Keep differential lock in [OFF] position under normal running condition. Differential may be damaged. -
Page 42: Parking
Operation Parking • Always park on a firm, level place. Never park on a potentially dangerous place. • Avoid parking on a slope. Never park on a slope with an incline of 10 degrees or steeper. If it is absolutely necessary to park machine on a slope less than 10 degrees, make certain to apply parking brake firmly and block wheels with chocks. - Page 43 Operation Move auxiliary transmission shift lever to [N (neutral)] position. Auxiliary Transmission Shift Lever 5347M-0402-101E Turn main switch to [ (off)] to stop engine. Remove ignition key. Main Switch 5332M-0402-210E Close fuel cock. Fuel Cock Close Open 5355M-0402-090E -34-...
-
Page 44: Working
Operation Working Inspecting Cutting Blade Inspect cutting blade before work. Refer to Cutting Blades (page 66) for inspection procedure. Adjusting Cutting Height Grab cutting height lock to unlock cutting height Cutting Height Adjust Lever adjust lever. Cutting Height Lock 5347M-0403-010E With lock button pulled up, move cutting Cutting Height Adjust Lever height adjust lever to a desired position. -
Page 45: Cutting
Operation Cutting • Never place any part of body under cutting blade shield. • Always wear protective footwear, long trousers, hardhat, safety glasses and ear protection when operating or servicing the machine. Proper clothing will minimize the chance of injury. Do not operate the equipment if you have long hair, loose clothing, or jewelry;... - Page 46 Operation • Always stay on machine when mowing. • Make sure air intake for cooling is not clogged or blocked. If it is clogged or blocked, it causes overheating, resulting in damages to machine. • When working in a dusty area, clean air cleaner element twice a day. Dirty air cleaner element results in poor starting, poor performance, or short life.
- Page 47 Operation Make sure cutting blade shield is closed. Cutting Blade Shield 5355M-0403-060E Turn throttle lever to [ (fast)] position to raise engine speed. Throttle Lever 5347M-0402-110E Move auxiliary transmission shift lever to [L (low speed)]. Auxiliary Transmission Shift Lever 5347M-0403-071E -38-...
- Page 48 Operation Move cutting height adjust lever to a desired Cutting Height Adjust Lever height. 5347M-0403-020E Move rotary clutch lever to [ON] to start Cutting Rotary cutting blade. Clutch Lever NOTE • Safety feature: engine stops automatically if operator leaves seat while cutting blade is rotating.
- Page 49 Operation Move cutting rotary clutch lever to [OFF] to Cutting Rotery stop cutting blade. Clutch Lever NOTE • Moving cutting rotary clutch lever to [OFF] applies brake on cutting blade to stop. 5347M-0402-020E Move cutting height adjust lever to the highest position.
-
Page 50: Maintenance
Every 500 hours (do more frequently in dusty place) Clean carburator Every 500 hours (clean more frequently in dusty place) Perform valve lapping Every 500 hours (clean more frequently in dusty place) Replace fuel hose Every two years Overhaul 1000 hours (contact Canycom representative for overhaul) -41-... -
Page 51: Chassis
• Perform a pre-startup inspection (PSI) before each use, a monthly inspection once a month, and a yearly inspection once a year. • Some maintenance procedures described below may require special knowledge or tools and instruments. Contact your CANYCOM representative to perform such procedures. Schedule... - Page 52 Maintenance Schedule Item Description Note Belt tension shall be properly adjusted. √ √ V-belt Belt shall be free of damage or excessive √ √ wear. √ √ √ Brake Brake shall work properly. Page 65 Parking brake shall be able to hold the √...
- Page 53 Maintenance Schedule Item Description Note Charging Charging system shall charge battery. √ System Battery fluid (electrolyte) shall be of proper Page 71 √ √ level. Battery Terminals shall be free of looseness or √ √ excessive corrosion. Head shall work. √...
-
Page 54: List Of Fluids And Lubricants
Maintenance List of Fluids and Lubricants Item Schedule Grade Cap. Fuel As needed. Automotive Unleaded Gasoline 7.0L Engine Oil Fill Gasoline Engine Oil Inspect daily. Fill as needed. API rating: SE or better. Change SAE rating: 10W-30 1.2L Initially - After 20 hours of use. Every 100 hours afterwards. -
Page 55: Greasing Points
Maintenance Greasing Points • Grease regularly. Insufficient greasing may result in seizure or rusting, affecting smooth operation of machine. NOTE • When using a manual grease pump, push handle five to six times. When handle becomes heavy, stop pushing. • When using a pneumatic grease pump, charge for two to three seconds. •... -
Page 56: Greasing Points (Cm1401)
Maintenance Greasing Points (CM1401) Location Schedule Grade Front knuckles Every 6 Months Chassis Grease Cutting rotary link pivots Every 6 Months Chassis Grease Cutting rotary drive shaft Every 6 Months Chassis Grease Front axle center pivot Every 6 Months Chassis Grease Side shield Every 6 Months Chassis Grease... -
Page 57: List Of Consumables And Spares
Maintenance List of Consumables and Spares • When replacing consumable or spare, always use CANYCOM genuine parts. Using non-CANYCOM parts may reduce machine's performance or service life. Note that it may also void warranty and certification for relevant standards. Item Part No. - Page 58 Maintenance Item Part No. Schedule Qty. Drive Train Wire (Differential Lock) 53323402000 Replace if defective. Wire (AWD)*1 53323452000 Replace if defective. Cooling Fan 53352023000 Replace if defective. Cutting System Blade Set (Silver) Z3214206010 Replace if defective. V-belt 08521600037 Replace if defective. Rubber Plate (Front Skirt, Center)*1 53322114000 Replace if defective.
-
Page 59: Removing And Installing Body Panels
Maintenance Removing and Installing Body Panels • Cut or pinch hazard exists when removing or installing body panels; beware of sharp edges and pinch points. • Make certain to reinstall panels after removing for repairs or inspection. Front Cover Pull top side of front cover to unlock latch. Front Cover Latch 5347M-0401-040E... -
Page 60: Head Lamp
Maintenance Head Lamp Remove front cover. Remove 2 knob bolts fixing the tray. Tray Knob Bolt Remove fixing bracket and lift tray. Fixing Bracket 5332M-0509-030E Remove 2 flange bolts fixing head lamp unit Flange Bolt to remove head lamp unit. Head Lamp Unit 5347M-0509-040E Insert projections at the bottom of head lamp... -
Page 61: Lower Rear Cover
Maintenance Lower Rear Cover Remove 4 bolts. Remove lower rear cover. Lower Rear Cover 5355M-0505-040E Rear Fender Remove 3 bolts. Remove rear fender. NOTE • Right-hand side shown.Same on the left- hand side. Rear Fender 5355M-0505-050E Step Remove 3 bolts fixing step. Step Remove step. -
Page 62: Seat Bracket
Maintenance Seat Bracket • Always slide seat to the rear-most position when lifting seat. If seat is not in the rear-most position, slide lever may interfere with step, preventing seat to be lifted to the holding position. Slide seat to the rear-most position. Safety Pin Lift seat and push safety pin toward inside to hold seat. - Page 63 Maintenance Flipping up shield Lock Pin Push lock pin to unlock shield. Lock Lever Pull up lock lever and move shield up or down to one of three positions. Cutting Blade Shield Press down lock lever to lock shield. Lock pin will also return to lock position automatically.
-
Page 64: Engine
Maintenance Engine • Always stop engine and remove ignition key before servicing. • An engine that has been running is very hot. Allow engine to cool before servicing, or severe burns may result. • Keep fire and spark away when servicing. Engine Oil •... - Page 65 Maintenance Visually inspect oil level. Make sure oil level is between upper and lower limits. If it is below lower limit, add oil. Visually inspect condition of oil. If it is too Upper Limit dirty or viscosity is not normal, change oil. Screw oil filler cap back in place.
-
Page 66: Air Cleaner
Maintenance Air Cleaner • Clean air cleaner element daily. Dirty air cleaner element causes poor starting, reduces engine performance and shortens engine life. • Replace air cleaner element if damaged. Undo latches and pull out air cleaner case. Follow the instructions in Operator's Manual for the engine to inspect, clean or change Air Cleaner Case air cleaner element. -
Page 67: Spark Plugs
Maintenance Spark Plug • Never pull ignition cable when removing a spark plug cap. Conductor in the cable may be severed or damaged. • If a spark plug is damaged, replace it with a new one. Follow the instructions in Operator's Manual Spark Plug Cap for the engine to inspect, clean, or change spark plug. -
Page 68: Drive Train
Maintenance Drive Train • Stop engine and remove ignition key when servicing drive train. • Allow machine to cool off before servicing. Engine and its ancillaries are very hot after operation and may pose a burn hazard. • Dispose of drained oil properly. Tires •... -
Page 69: Transmission Oil
Maintenance Transmission Oil NOTE • Oil to use and capacity: Page 45. Park machine on level ground. Have an appropriate oil drain pan. Drain Plug Remove transmission oil drain plug to drain oil. Install drain plug back in place. Check Bolt 5332M-0507-040E Remove upper rear cover. -
Page 70: Hst (Hydrostatic Transmission) Fluid
Maintenance NOTE • Drain plug for the right front knucle is on the back side of the front axle. Install both drain plugs back in place. Filler Plug Remove right front step. Remove oil filler cap. Fill specified amount of oil into filler. Install filler plug back in place. - Page 71 Maintenance Inspecting HST Oil Reservoir Park machine on level ground. Remove right rear fender. Visually inspect that oil level is between [MIN] and [MAX] lines on oil reservoir. If it is below [MIN], fill oil. Install right rear fender. 5355M-0507-020E Filling Remove right rear fender.
- Page 72 Maintenance Reinstall drain plug. Fill fresh oil to level. Reinstall filler cap. Reinstall lower rear cover and install right rear fender. 10. Start engine and run it for a while. Stop it and check HST oil level. 11. Restart engine and drive machine back-and-forth from standstill several times. 12.
-
Page 73: Drive Belt
10 to 20 mm. If it is out of this range, adjust with adjust nut. Visually inspect belt. Replace belt if it is damaged. For replacement, contact your CANYCOM representative. Spring Install upper and lower rear covers. Adjust Nut... -
Page 74: Parking Brake
5347M-0507-070E NOTE • If brake does not work even the brake pedal is locked, the brake shoe is worn out. Please contact your CANYCOM representative for replacement. Front Brake (CMX1402) Lock brake pedal and inspect that the strech of spring is between 5mm and 8mm. If it is not within this range, adjust it with adjust nut. -
Page 75: Cutting System
Maintenance Cutting System • Stop engine and remove ignition key when servicing. • Allow machine to cool off before servicing. Engine and its ancillaries are very hot after operation and may pose a burn hazard. Cutting Blades • When a blade is damaged, replace it and the other blade immediately. Always replace blades in pair. - Page 76 Maintenance Replacing Stick-like Object Open cutting blade shield. Hold blade with a strong stick-like object (such as screw driver). 5323M-0509-060E Unfasten nut A, then nut B to remove blade. Nut A Place a new or flipped blade under blade NutB stay.
-
Page 77: Cutting Rotary Drive Belt
Turn cutting rotary clutch lever to [ON]. Inspect the condition of V-belt to be free of damages or wear. Replace if damaged or Spring worn. Contact your CANYCOM representative for replacement. Notch Visually inspect if washer that holds spring is... -
Page 78: Cutting Rotary Brake
5355M-0508-020E V-belt needs to be replaced. Contact your CANYCOM representative for replacement. Reinstall upper and lower rear cover. Cutting Rotary Brake • Never place any part of body under cutting blade shield when cutting blade is rotating. - Page 79 Maintenance • Inspect cutting rotary brake whenever the performance of it seems inadequate. • Stop engine when adjusting cutting rotary brake. Inspecting Start engine. Turn throttle lever to [ (fast)] to raise engine speed. Move cutting height adjust lever to [150]. Move cutting rotary clutch lever to [ON] to rotate cutting blade.
-
Page 80: Electrical System
Maintenance Move cutting rotary clutch lever to [OFF]. Visually inspect if lining is firmly in contact Lock Nut with lining groove on pulley. Shake turnbuckle to see if there is some play. Turnbuckle If lining is not firmly in contact with the Lining groove, or turnbuckle is too tight, readjust turnbuckle. - Page 81 Maintenance • Always disconnect (-) terminal first, and connect (+) terminal first. Disconnecting or connecting in the opposite order may cause a short circuit. • When installing battery, make certain to connect (+) and (-) terminals to their original positions. Avoid contact between terminals and other surrounding parts.
-
Page 82: Fuses
Maintenance Filling Filler Cap Remove front cover. Remove battery. Remove filler cap. Fill distilled water to "UPPER LEVEL" line. Install filler cap. Install battery. Install front cover. 5321M-0510-020E Charging Remove front cover. Remove battery from machine. Follow instructions in battery charger user's manual to charge battery. -
Page 83: Light Bulbs
Maintenance Light Bulbs • When light bulb is burnt out, replace it with a new bulb. • When replacing, always use a bulb of the correct rating. Wrong bulb may cause malfunction or damge in electrical system. • Do not touch bulb when it is hot. It may cause burns. •... -
Page 84: After Use Care
Maintenance After Use Care Cutting System • Never place any part of body under cutting blade shield when cutting blade is rotating. • Do not allow bystanders to come near machine when cutting blade is rotating. • Always stay on machine when performing this opeartion •... -
Page 85: After Normal Use
Maintenance After Normal Use • Fire hazard; clean machine of cut grass and similar material after use. Cut grass that is accumulated on the machine can catch fire. • Clean cooling air intake in front of the engine. If cooling air intake is clogged or blocked, it causes overheating, resulting in damages to the machine. -
Page 86: After Cold Weather Use
Maintenance After Cold Weather Use • Fire hazard; clean machine of cut grass and similar material after use. Cut grass that is accumulated on the machine can catch fire. • Do not wash engine or control panel with running water; water may enter inside and cause rust or damage. -
Page 87: Storage
Maintenance Storage • Fire hazard; do not store machine where there is a possiblity of ignition. • Do not wash engine or control panel with running water; water may enter inside and cause rust or damage. • Clean machine before storage; dirt or foreign objects may freeze and cause damage. -
Page 88: Troubleshooting
Troubleshooting chart below. If the malfunction or abnormal condition is not listed in the chart, or the suggested measure does not solve the problem, consult with your CANYCOM representative. • Some corrective measures listed below require special knowledge and/or equipment. - Page 89 →Clean or replace the Page 57 (clogged air cleaner). air cleaner. Idling is not stable. Other (other than the →Please contact above). your CANYCOM representative. Bad fuel →Change fuel. Insufficient intake air →Clean or replace the Page 57 (clogged air cleaner).
- Page 90 V-belt is loose. →Adjust V-belt. Page 64 or pedal is operated. Other (other than the →Please contact above). your CANYCOM representative. Machine moves when HST is out of neutral. →Please contact drive lever or pedal is your CANYCOM in neutral position.
- Page 91 Page 74 Electrical Head lamp does not Other (other than the →Please contact System illuminate properly. above). your CANYCOM representative. Cutting blade does not Cutting rotary drive →Replace. rotate belt is severed. Cutting blade does not Brake lining is worn.
- Page 92 Troubleshooting Area Malfunction Possible Cause Corrective Measure Ref. Cutting height is too →Raise cutting height. low. Machine turns too fast. →Turn slowly. Cutting blade cuts into Work site has →Raise cutting height. ground. undulations. Cutting Cutting blade (knives →Replace. System or stay) is bent.
- Page 93 Transporting Hauling Loading and Unloading • Park transporter (truck) on a level ground. Always apply parking brake and use chocks to secure wheels. • Do not allow bystandars to come close to machine or transporter when loading or unloading machine. •...
- Page 94 Transporting Place loading ramps. Secure hooks oframps firmly and flush with loading deck. Shift auxiliary transmission shift lever to [Low] and drive machine slowly forward onto loading deck. Set cutting height adjust lever to [150]. Pay attention not to hit loading lamp or loading deck when loading on a transporter.
- Page 95 NOISE LEVEL Model Engine Type Type Speed rpm CMX1402 Robin EX40DS 3500 rpm 100 dB (A) NOISE LEVEL evaluated based on factory standard. VIBRATION Vibration Engine Steering Model Mower Blade Steering Rated revolution wheel Seat Clutch wheel (top) (bottom) 16m/s 14m/s 2.7m/s CMX1402...
