Locking Differential

Differential can be locked to minimize slipping on slippery surface.
• Always stop machine to operate differential lock lever. Operating differential
lock lever while machine is in motion can damage differential.
• Keep differential lock in [OFF] position under normal running condition.
Differential may be damaged.
• Do not turn machine when differential lock is in [ON] position.
5347M-0402-180E
5347M-0402-190E
Operation
Differential Lock Lever
Differential Lock Lever
1. Move differential lock lever to [ON] position.
2. Move auxiliary transmission shift lever to [L
(low speed)] position.
3. Drive slowly out of the slippery area.
4. Once machine is out of the slippery area,
stop and move differential lock lever to [OFF]
position.
-32-
