Adjusting Drive Pedal - CanyCom Masao CMX1402 Operator's Manual

4
Seat Switch Bracket
Bolts
5335M-0401-010E

Adjusting Drive Pedal

• Always check if the drive pedal is fixed firmly after adjusting.
Drive Pedal
5332M-0401-100E
Operation
Adjusting Height (Rear Part)
1.
2.
NOTE
• Move seat and to check if the seat is locked
• Height at the rear can be adjusted in 4 levels
• Seat switch bracket is mounted in the
3.
4.
5.
1.
Pedal (Forward)
2.
NOTE
• Drive pedal can be adjusted in 3 positions
Bolts
Slide seat to the rear-most position.
Pull up seat and push safety pin toward
inside to hold seat lifted.
securely.
heighest position when shipped from
factory.
Remove 2 bolts fixing seat switch bracket.
Move seat switch bracket into desired
position and fix with bolts firmly.
Pull safety pin back and lower the seat.
Remove two bolts fixing forward pedal with
drive pedal.
Adjust the pedal (forward) into the desired
position and fix with bolts.
and angle.
-22-
