Shifting Between 2WD and AWD (CMX1402)

• Always stop machine to shift between 2WD or AWD (all-wheel-drive) modes.
Shifting gears while machine is in motion can damage transmission.
• Use 2WD mode under normal condition.
• Pay attention to the minimum turning radius in AWD mode. In AWD mode,
minimum turning radius is greater than that in 2WD mode.
2WD/AWD Shift Lever
5347M-0402-170E
Operation
1. Stop machine.
2. Move 2WD/AWD shift lever to [2WD] or
[AWD] position firmly.
