After Use Care

Cutting System

• Never place any part of the body under the cutting blade shield when mower is
running.
• Do not allow bystanders to come near the machine when the mower is running.
• Always stay on the machine when performing this operation
• Never attempt to clean the cutting system with the cutting blade shield open.
Stones or rocks can be thrown and cause damage to surrounding properties or
persons.
• Turn the mower clutch to [ON] only when cleaning. Keep it in [OFF] position all
the other times.
Hose Connection
5335M-0510-010E
Maintenance
1. Park the machine.
2. Set the cutting height to about 50mm.
3. Connect a hose to the hose connection.
Run water through the hose.
4. Start the engine.
5. Turn the throttle lever to [
the engine speed.
6. Move the mower clutch lever to [ON] to run
the mower to clean.
-79-
5
] (fast) to raise
