Cutting Rotary Drive Belt

• Never place any part of body under cutting blade shield when cutting blade is
rotating.
• Do not allow bystanders to come near machine when inspecting cutting rotary
drive belt.
• Adjust belt tension properly. Inproperly tensioned belt may reduce performance
and its service life.
NOTE
• The V-belt stretches (breaks in) when it is new. Inspect and adjust the V-belt after
the first day's (4 hours') use.
• For a longer service life, inspect and adjust (as necessary) the V-belt as the daily
pre-start up checks.
Washer
5355M-0508-010E
Maintenance
Inspecting and Adjusting
1.
2.
3.
Spring
Notch
4.
Remove upper and lower rear cover.
Turn cutting rotary clutch lever to [ON].
Inspect the condition of V-belt to be free of
damages or wear. Replace if damaged or
worn. Contact your CANYCOM
representative for replacement.
Visually inspect if washer that holds spring is
aligned with the right side of the notches on
plates as shown.
-68-
