Working

Inspecting Cutting Blade

Inspect cutting blade before work. Refer to Cutting Blades (page 66) for inspection
procedure.

Adjusting Cutting Height

Cutting Height Adjust Lever
Cutting Height Lock
5347M-0403-010E
Cutting Height Adjust Lever
5347M-0403-020E
NOTE
• Cutting Height Range: 0mm - 150mm
• Cutting Height indicated on the side of the adjust lever is for reference purpose
only; actual cutting height may vary due to the condition of ground or brush, and
other factors.
GL
5355M-0403-100
Operation
1. Grab cutting height lock to unlock cutting height
adjust lever.
2. With lock button pulled up, move cutting
height adjust lever to a desired position.
3. Release lock to lock cutting height adjust
lever.
135
Stopped
150 Running
-35-
