Adjusting Height (Front Part)
Height of seat at front can be set in one of two positions.
NOTE
• Height of seat at front is set at the low position when shipped from the factory.
• Seat switch bracket at the back needs to be in the highest position when setting the
front in high position.
Safety Pin
5355M-0401-080E
Pivot Pin
Seat hinge Bracket
5355M-0401-090E
2
5355M-0401-100E
Operation
Bolt
1
1. Pull up seat and push safety pin toward
inside to hold seat lift up.
2. Undo 2 bolts to remove seat.
3. Remove pivot pin to remove seat hinge
bracket.
4. (1)Raise seat hinge bracket and (2) turn it
around 180 degrees, then mount it to seat
with pivot pin.
5. Mount seat with newly repositioned seat
bracket to floor.
