Adjusting Seating Position - CanyCom Masao CMX1402 Operator's Manual

4

Adjusting Seating Position

• Beware of pinch points when adjusting seating position.
• After adjusting seat, try moving seat back and forth and up and down to make
sure it is securely locked in its position.
Slide Lever
5347M-0401-050E
5347M-0401-060E
5347M-0401-070E
Operation
Seat
Seat Suspension
Stiffness Adjust Lever
Reclining Adjust Knob
Sliding seat
1. Pull slide lever to the right to slide seat
forward or backward.
2. When seat is in a desired position, release
slide lever and lock seat securely.
Adjusting Stiffness
1. Move seat suspension stiffness adjust lever
to adjust desired seat stiffness.
Adjusting Reclining Angle
1. Rotate reclining adjust knob on the right of
seat to adjust reclining angle of the seat.
NOTE
• Do not ajust seat posision to the end and
recline the seat. The seat may contact with
rear cover. This may activate seat switch
and stop engine. Adjust seat within the
range of not contacting with rear cover.
-20-
