2
10 Differential Lock Lever . . . . Differential lock lever is used to lock differential when rear
11 Cutting Height Adjust . . . . . Cutting height adjust lever is used to adjust the cutting
Lever
12 Cutting Height Adjust
Lock
13 Cutting Rotary Clutch . . . . . Cutting rotary clutch lever is used to start or stop rotating
Lever
14 Tilt Lever . . . . . . . . . . . . . . . . Tilt lever is used to adjust the angle of steering wheel.
15 Head Lamp Switch . . . . . . . . Head lamp switch is used to turn on or off head lamp.
16 Fuel Gauge . . . . . . . . . . . . . . Fuel gauge indicates the amount of fuel in fuel tank.
17 Hour Meter . . . . . . . . . . . . . . Hour meter indicates the cumulative total operating time of
Controls and Components
wheels slip. Tilting differential lock lever to [ON] position
locks differential.
height. Grab and hold cutting height adjust lock and move
cutting height adjust lever back or forth to adjust cutting
height.
cutting rotary.
When umain switch is on, head lamp switch illuminates.
the machine in 0.1 hour increments.
-14-
