Bill of Materials
Designator Quantity Value Description
J2 1 Header (shrouded), 100
mil, 5 × 2, Gold, TH
JP1, JP2 2 Header, 100 mil, 3 × 1,
Gold, TH
JP3, JP4 2 Header, 100 mil, 3 × 2,
Gold, TH
JP5, JP6 2 Header, 2.54 mm, 2 × 1,
Gold, TH
JP7, JP8 2 Header, 100mil, 2 × 1, Tin,
TH
LBL1 1 Thermal Transfer Printable
Labels, 0.650" W × 0.200"
H - 10,000 per roll
LED1 1 Green LED, Green, SMD
R1, R3 2 10 RES, 10, 5%, 0.1 W, AEC-
Q200 Grade 0, 0603
R2, R6 2 30.1 k RES, 30.1 k, 1%, 0.1 W,
0603
R4, R8 2 11.0 k RES, 11.0 k, 1%, 0.1 W,
0603
R7, R14, R36, 4 10 RES, 10.0, 1%, 0.063 W,
R41 0402
R9, R10, R12, 8 49.9 RES, 49.9, 1%, 0.1 W,
R13, R37, AEC-Q200 Grade 0, 0402
R38, R39,
R40
R19, R20, 4 0 RES, 0, 5%, 0.1 W, AEC-
R21, R32 Q200 Grade 0, 0603
R22 1 14.7 k RES, 14.7 k, 1%, 0.1 W,
AEC-Q200 Grade 0, 0603
R23 1 10.0 k RES, 10.0 k, 1%, 0.1 W,
0603
R24, R35 2 14.7 k RES, 14.7 k, 1%, 0.1 W,
0603
R25, R31 2 10.0 k RES, 10.0 k, 1%, 0.1 W,
0603
R29, R34 2 26.1 k RES, 26.1 k, 1%, 0.1 W,
0603
R33 1 68.1 k RES, 68.1 k, 0.1%, 0.1 W,
0603
20 TPSM8D6C24EVM-2V0 User's Guide
Table 9-1. TPSM8D624EVM-2V0 Bill of Materials (continued)
PackageReference
5 × 2 Shrouded header
PBC03SAAN
Sullins 100 mil, 2 × 3, 230 mil
above insulator
Header, 2.54 mm, 2 × 1, TH
Header, 2 × 1, 100 mil, TH
PCB Label 0.650 × 0.200
inch
LED_0603
603
603
603
402
402
603
603
603
603
603
603
603
Copyright © 2021 Texas Instruments Incorporated
PartNumber Manufacturer
5103308-1 TE Connectivity
PBC03SAAN Sullins Connector
Solutions
PBC03DAAN Sullins Connector
Solutions
61300211121 Wurth Elektronik
5-146278-2 TE Connectivity
THT-14-423-10 Brady
150060GS75000 Wurth Elektronik
CRCW060310R0JNEA Vishay-Dale
RC0603FR-0730K1L Yageo
RC0603FR-0711KL Yageo
CRCW040210R0FKED Vishay-Dale
ERJ-2RKF49R9X Panasonic
ERJ-3GEY0R00V Panasonic
ERJ-3EKF1472V Panasonic
RCG060310K0FKEA Vishay Draloric
RC0603FR-0714K7L Yageo
RC0603FR-0710KL Yageo
CRCW060326K1FKEA Vishay-Dale
RG1608P-6812-B-T5 Susumu Co Ltd
