    User's Guide SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module This user’s guide contains information for the TPSM831D31EVM evaluation module (BSR048). This guide provides information regarding the proper setup and use of the board to permit an in-depth evaluation of the performance and characteristics of the power module.

  • Page 2: Description

    Description The TPSM831D31 is a PMBus-controlled, dual output 4-phase power module that combines a high- performance DCAP+ controller with four high-efficiency smart power stages and low-loss inductors, into a rugged, thermally enhanced surface-mount package. The first output is configured as a 3-phase power stage that can deliver up to 120 A of continuous output current.

  • Page 3: Evm User Interface

    VOUT_A rail. It is strongly suggested that the scope connections be made with VOUT_A turned off. SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
  • Page 4 D1 (USB) will glow green. The LED will light even if no input power is applied to the EVM. The PMBus address is set by resistor R10. The PMBus address of the EVM is set to 105 (decimal), 69 (hex). Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback...

  • Page 5: Test Point Descriptions

    SMB jack input from external function generator to drive the VOUT_B fast transient generator. B_Imon (J14) SMB jack for current monitor output of VOUT_B transient generator. 3mV/A, 50Ω output impedance. SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...

  • Page 6: Connecting The Evm

    The GUI may identify the device as a TPS53681. This is normal. That is the device used as the controller in the module. Figure 2. Example Test Setup Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback...

  • Page 7: Using The Fusion Digital Power Designer Gui

    Store Config to NVM command stores any and all new settings to NVM. The original factory settings cannot be restored if they are altered. SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...

  • Page 8: Configuration Window: General Tab

    Axis limits can be set within each plot. Start/Stop Polling button starts or stops the collection of data over the PMBus. Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback Copyright ©...

  • Page 9: Monitor Window: Parametric Data Plots

    This window offers another way to select and display the telemetry data. You can customize the display to your liking. Figure 7. System Monitor Window: Control Lines SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...

  • Page 10: Usb Adapter Settings

    Remember that the “Store Config to NVM” button permanently stores any changes made to settings that have NVM backup. The factory settings cannot be recalled once they are overwritten. Figure 8. USB Adapter Settings Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback...

  • Page 11: Using The On-Board Fast Transient Load Generator

    Using the On-board Fast Transient Load Generator The TPSM831D31 is equipped with two high speed transient load circuits, one for each output rail. The transient load circuits are capable of producing load transients up to 60 A at slew rates in excess of 100 A/µs.

  • Page 12: Function Generator Settings

    (Some oscilloscopes allow the user to set the channel to display current per division. The EVM Imon signal is equivalent to 333 A/V.) Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback...

  • Page 13: Response To 60 A, 100 A/Μs Load Transient

    The results should be similar to that shown Figure Figure 11. Response to 60 A, 100 A/µs Load Transient SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...

  • Page 14: Evaluation Board Schematic

    Evaluation Board Schematic www.ti.com Evaluation Board Schematic Figure 12. EVM Schematic Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...

  • Page 15: Bill Of Materials (Bom)

    RES, 49.9, 1%, 0.25 W, 1206 CRCW120649R9FKEA Vishay-Dale R16, R24 3.24k RES, 3.24 k, 1%, 0.1 W, 0603 CRCW06033K24FKEA Vishay-Dale SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
  • Page 16 High Bandwidth, High Precision, Low Noise & U4, U5 Distortion Amplifier SAR ADC Driver with Power OPA625IDBVR Texas Instruments Scaling, DBV0006A (SOT-23-6) Using the TPSM831D31 Power Module Evaluation Module SNAU240 – August 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
  • Page 17 SNAU240 – August 2018 Using the TPSM831D31 Power Module Evaluation Module Submit Documentation Feedback...
