Signal Source
External
Gating
Switch
Note that the signals shown for the STP268 screw terminal panel
correspond to connector J1.
Note that you can internally cascade counters using software; if you
internally cascade the counters, you do not have to make the
external cascading connections. Note also that this example shows
the use of an external gate; however, this connection is not required.
Figure 39: Cascading Counters on an STP268 Screw Terminal Panel
(Shown for Event Counting Using Counters 0 and 1 and External Gate 0)
Figure 40, Figure 41, and
STP268-EC screw terminal panel.
User Clock Input 0
Gate 0
Gate 1
Digital Ground
Figure 42 show examples of connecting event counting signals to the
STP268 Panel
User
Counter
TB54
Output 0
TB55
TB56
TB57
TB58
User Clock
Input 1
TB60
Wiring Signals
