This manual describes how to set up and install the following components:
• DT3010 Series software
• DT3010 Series board
• DT3010 Series Device Driver
• DT740, STP268, or STP268-EC screw terminal panel
It describes how to wire signals to the board and how to verify the board's operation using the
Quick DataAcq application.
This manual also describes the features of the DT3010, DT3010-268, DT3010/32,
DT3010/32-268, and DT3016 boards (collectively referred to as the DT3010 Series), the
capabilities of the DT3010 Series Device Driver, and how to program the DT3010 Series boards
using the DT-Open Layers for .NET Class Library™ software. Troubleshooting and calibration
information is also provided.
Note: For information on checking system requirements, installing the software, and
viewing the documentation, refer to the README file on the OMNI CD.
For more information on the class library, refer to the DT-Open Layers for .NET Class Library
User's Manual. If you are using the DataAcq SDK or a software application to program your
device, refer to the documentation for that software for more information.
Intended Audience
This document is intended for engineers, scientists, technicians, or others responsible for
using and/or programming the DT3010 Series boards for data acquisition operations in
Microsoft® Windows® XP, Windows Vista®, or Windows 7. It is assumed that you have some
familiarity with data acquisition principles, and that you understand your application.
How this Manual is Organized
This manual is organized as follows:
•
Chapter
1,
software and accessories for the board, and provides an overview of the getting started
procedure.
•
Chapter
2,
the DT3010 Series board and load the DT3010 Series Device Driver.
•
Chapter
3,
the DT740, STP268, or STP268-EC screw terminal panel to a DT3010 Series board and how
to configure the screw terminal panel for use with a DT3010 Series board.
"Overview,"
describes the major features of the board, as well as the supported
"Installing the Board and Loading the Device Driver,"
"Attaching and Configuring a Screw Terminal Panel,"
About this Manual
describes how to install
describes how to attach
11
