Chapter 8
Figure 78: Location of Potentiometers R12 to R15 on the DT3010, DT3010-268, DT3010/32,
9. In the Voltages box, select +9.3750.
10. Physically adjust potentiometer R14 (labelled 0G) on the DT3010, DT3010-268,
11. In the D/A box, select DAC 1.
12. In the Voltages box, select –9.3750.
13. Physically adjust potentiometer R13 (labelled 1Z) on the DT3010, DT3010-268,
14. In the Voltages box, select + 9.3750.
15. Physically adjust potentiometer R12 (labelled 1G) on the DT3010, DT3010-268,
16. Click Quit when you are finished calibrating the analog output circuitry.
Once you have finished this procedure, the analog output circuitry is calibrated. To close the
DT3010 Calibration Utility, click the close box in the upper, right corner of the window.
172
DT3010/32, or DT3010/32-268 board until the display reads +9.3750 V (within 0.001 V).
Figure 78 shows the location of this potentiometer.
DT3010/32, or DT3010/32-268 board until the display reads –9.3750 V (within 0.001 V).
Figure 78 shows the location of this potentiometer.
DT3010/32, or DT3010/32-268 board until the display reads +9.3750 V (within 0.001 V).
Figure 78 shows the location of this potentiometer.
Note: If you want to check the values for intermediate ranges, select Display Values in
the Mode box and select any of the available ranges; the range is then displayed. You
cannot calibrate intermediate ranges.
Potentiometers for the DACs
R12 -1G
and DT3010/32-268
R14 - 0G
R15 -
R13 -
0Z
1Z
