Appendix B
Connector J2 on the DT3010-268 and DT3010/32-268
Board
Table 40
board.
Table 40: Connector J2 Pin Assignments on the DT3010-268 and DT3010/32-268 Board
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
200
lists the pin assignments of connector J2 on the DT3010-268 and DT3010/32-268
Pin Signal Description
+5 V Output
User Counter Output 2
User Clock Input 2
Digital I/O Bank B2
Digital I/O Bank B0
Reserved
Dynamic Digital Output 0
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Digital Ground
External Gate 2
Digital Ground
Digital I/O Bank B6
Digital I/O Bank B4
Reserved
Reserved
Reserved
Reserved
Reserved
Pin Signal Description
2 User Counter Output 3
4 Digital Ground
6 Digital I/O Bank B3
8 Digital I/O Bank B1
10 Reserved
12 Reserved
14 Dynamic Digital Output 1
16 Reserved
18 Reserved
20 Reserved
22 Reserved
24 Reserved
26 Reserved
28 Reserved
30 Reserved
32 Reserved
34 Reserved
36 External Gate 3
38 User Clock Input 3
40 Digital I/O Bank B7
42 Digital I/O Bank B5
44 Reserved
46 Reserved
48 Digital Ground
50 Reserved
52 Reserved
54 Reserved
