3. When the bottom of the board contacts the bus connector, gently press down on the board
until it clicks into place.
Do not force the board into place. Moving the board from side to side
during installation may damage the bus connector. If you encounter
resistance when inserting the board, remove the board and try again.
4. Secure the board in place at the rear panel of the system unit using the screw removed
from the slot cover.
5. If you are installing a DT3010-268 board, secure the face plate of the EP324 cable into the
appropriate slot.
6. Reinstall the cover of the computer. Refer to your computer's user's manual for
instructions.
7. Power up the computer, and follow the steps in the next section.
Installing the Board and Loading the Device Driver
CAUTION:
