Measurement Computing Data Translation DT3010 Series User Manual page 211

Appendix B
Table 47: Screw Terminal Assignments for Connector J3 on the STP268-EC (cont.)
TB
51
61
63
65
67
a. Jumper W3 must be installed on the STP268-EC. If this jumper is not installed, this signal is not
available through this connector.
b. Jumper W2 must be installed on the STP268-EC. If this jumper is not installed, this signal is not
available through this connector.
c. Jumper W1 must be installed on the STP268-EC for DAC0 Ground; jumper W4 must be
installed on the STP268-EC for DAC1 Ground. If these jumpers are not installed, this signal is
not available through this connector.
d. If jumper W3 is installed on the STP268-EC, this signal is not available through this connector.
e. If jumper W2 is installed on the STP268-EC, this signal is not available through this connector.
Table 48
terminal panel.
Table 48: Screw Terminal Assignments for Connector J4 on the STP268-EC
TB
19
21
23
25
52
54
56
210
J3 Pin SIgnal Description
c
21, 24 Analog Ground
d
22 Analog Input 15
Analog Input 07 Return
16 Analog Input 13/
Analog Input 05 Return
10 Analog Input 11/
Analog Input 03 Return
4 Analog Input 09/
Analog Input 01 Return
lists the screw terminal assignments for connector J4 on the STP268-EC screw
J4 Pin SIgnal Description
23 Analog Input 23
17 Analog Input 21
11 Analog Input 19
5 Analog Input 17
3, 6, 9, Analog Ground
12, 15,
18, 21,
24
20 Analog Input 30
Analog Input 22 Return
14 Analog Input 28
Analog Input 20 Return
TB J3 Pin Signal Description
52 3, 6, 9, Analog Ground
12, 15,
18, 21,
24
62 20 Analog Input 14
Analog Input 06 Return
64 14 Analog Input 12/
Analog Input 04 Return
66 8 Analog Input 10/
Analog Input 02 Return
68 2 Analog Input 08/
Analog Input 00 Return
TB J4 Pin SIgnal Description
20 19 Analog Input 22
22 13 Analog Input 20
24 7 Analog Input 18
26 1 Analog Input 16
53 22 Analog Input 31
Analog Input 23 Return
55 16 Analog Input 29
Analog Input 21 Return
57 10 Analog Input 27
Analog Input 19 Return
e
/
