Table 5: Screw Terminal Assignments for Connector J2 on the STP268 (cont.)
J2
TB Pin
57 4, 35, Digital Ground
39
59 2 User Counter Output 3
61 9 Digital I/O Bank B0
63 7 Digital I/O Bank B2
65 43 Digital I/O Bank B4
67 41 Digital I/O Bank B6

STP268-EC Screw Terminal Assignments

The STP268-EC screw terminal provides connector J1 for attaching to the DT3010-268 or
DT3010/32-268 board, connector J2 for attaching to an Opto-22 backplane, and connectors J3
and J4 for attaching to 5B and/or 7B backplanes.
Table 6 lists the screw terminal assignments for connector J1 on the STP268-EC screw terminal
panel.
Table 6: Screw Terminal Assignments for Connector J1 on the STP268-EC
J1
TB Pin Signal Description
1 1 +5 V Output
3 3 User Counter Output 0
5 5 User Clock Input 0
7 7 Digital I/O Bank A2
9 9 Digital I/O Bank A0
11 11 +15 V Output
13 13 External A/D Sample Input
15 15 Analog Trigger
17 17 Analog Output 0+
19 19 Analog Input 23
21 21 Analog Input 21
23 23 Analog Input 19
25 25 Analog Input 17
27 27 Analog Input 07
29 29 Analog Input 05
Signal Description
J2
TB Pin Signal Description
58 38 User Clock Input 3
60 36 External Gate 3
62 8 Digital I/O Bank B1
64 6 Digital I/O Bank B3
66 42 Digital I/O Bank B5
68 40 Digital I/O Bank B7
J1
TB Pin Signal Description
2 2 User Counter Output 1
4 4 Digital Ground
6 6 Digital I/O Bank A3
8 8 Digital I/O Bank A1
10 10 External D/A TTL Trigger
− 15 V Output
12 12
14 14 External A/D TTL Trigger
16 16 Analog Output 1+
18 18 Amp Low
20 20 Analog Input 22
22 22 Analog Input 20
24 24 Analog Input 18
26 26 Analog Input 16
28 28 Analog Input 06
30 30 Analog Input 04
