Table 7 lists the screw terminal assignments for connector J2 on the STP268-EC screw terminal
panel.
Table 7: Screw Terminal Assignments for Connector J2 on the STP268-EC
TB J2 Pin Signal Description
6 41 Digital I/O 3
8 45 Digital I/O 1
40 33 Digital I/O 7
42 37 Digital I/O 5
Table 8 lists the screw terminal assignments for connector J3 on the STP268-EC screw terminal
panel.
Table 8: Screw Terminal Assignments for Connector J3 on the STP268-EC
TB J3 Pin SIgnal Description
16 22 DAC1_OUT
18 25 Amp Low
27 23 Analog Input 07
29 17 Analog Input 05
31 11 Analog Input 03
33 5 Analog Input 01
51 21, 24 Analog Ground
61 22 Analog Input 15
Analog Input 07 Return
63 16 Analog Input 13/
Analog Input 05 Return
65 10 Analog Input 11/
Analog Input 03 Return
67 4 Analog Input 09/
Analog Input 01 Return
a. Jumper W3 must be installed on the STP268-EC. If this jumper is not installed, this signal is not
available through this connector.
b. Jumper W2 must be installed on the STP268-EC. If this jumper is not installed, this signal is not
available through this connector.
c. Jumper W1 must be installed on the STP268-EC for DAC0 Ground; jumper W4 must be
installed on the STP268-EC for DAC1 Ground. If these jumpers are not installed, this signal is
not available through this connector.
d. If jumper W3 is installed on the STP268-EC, this signal is not available through this connector.
e. If jumper W2 is installed on the STP268-EC, this signal is not available through this connector.
TB J2 Pin
7 43
9 47
41 35
43 39
TB J3 Pin
a
17 20
−
26
28 19
30 13
32 7
34 1
c
52 3, 6, 9,
12, 15,
18, 21,
24
d
62 20
64 14
66 8
68 2
Signal Description
Digital I/O 2
Digital I/O 0
Digital I/O 6
Digital I/O 4
Signal Description
b
DAC0_OUT
Not Connected
Analog Input 06
Analog Input 04
Analog Input 02
Analog Input 00
Analog Ground
e
Analog Input 14 /
Analog Input 06 Return
Analog Input 12/
Analog Input 04 Return
Analog Input 10/
Analog Input 02 Return
Analog Input 08/
Analog Input 00 Return
