Screw Terminal Assignments for the STP268

Table 43 lists the screw terminal assignments for the STP268 screw terminal panel attached to
connector J1 on the DT3010-286.
Table 43: Screw Terminal Assignments for the STP268 Attached to Connector J1
TB J1 Pin
1 34
3 33
5 32
7 31
9 30
11 29
13 28
15 27
17 26
19 25
21 24
23 23
25 22
27 21
29 20
31 19
33 18
35 11
37 12
Signal Description
Analog Input 00
Analog Input 01
Analog Input 02
Analog Input 03
Analog Input 04
Analog Input 05
Analog Input 06
Analog Input 07
Analog Input 16
Analog Input 17
Analog Input 18
Analog Input 19
Analog Input 20
Analog Input 21
Analog Input 22
Analog Input 23
Amp Low
+15 V Output
−
15 V Output
TB J1 Pin Signal Description
2 68 Analog Input 08/
Analog Input 00 Return
4 67 Analog Input 09/
Analog Input 01 Return
6 66 Analog Input 10/
Analog Input 02 Return
8 65 Analog Input 11/
Analog Input 03 Return
10 64 Analog Input 12/
Analog Input 04 Return
12 63 Analog Input 13/
Analog Input 05 Return
14 62 Analog Input 14/
Analog Input 06 Return
16 61 Analog Input 15/
Analog Input 07 Return
18 60 Analog Input 24/
Analog Input 16 Return
20 59 Analog Input 25/
Analog Input 17 Return
22 58 Analog Input 26/
Analog Input 18 Return
24 57 Analog Input 27/
Analog Input 19 Return
26 56 Analog Input 28/
Analog Input 20 Return
28 55 Analog Input 29/
Analog Input 21 Return
30 54 Analog Input 30/
Analog Input 22 Return
32 53 Analog Input 31/
Analog Input 23 Return
34 49 Analog Ground
36 45 Power Ground
38 46 A/D Trigger Output
