Chapter 2

Inserting the DT3010 Series Board into the Computer

Once you have set up the expansion slots and connected the EP324 cable to the board (if
needed), do the following to insert the DT3010 Series board into the computer:
1. Position the board so that the cable connectors are facing the rear of the computer.
2. Carefully lower the board into the PCI expansion slot using the card guide to properly
32
3 shows an example of inserting a DT3010, DT3010/32, DT3010/32-268, and DT3016
board. Figure 4 shows an example of inserting a DT3010-268 board.
Rear of Computer
Figure 3: Inserting the DT3010 Series Board in the Computer
Rear of Computer
PCI Expansion Slot Bus Connector
Figure 4: Inserting the DT3010-268 Board in the Computer
align the board in the slot.
DT3010, DT3010/32,
PCI Expansion Slot Bus Connector
EP324 Cable and
Face Plate
DT3010/32-268, or
DT3016
DT3010-268
Board
Figure
