Chapter 4
External
Gating
Switch
80
Signal Source
Note that the signals shown for the STP268 screw terminal
panel correspond to connector J1. In this example, rising
Figure 37: Connecting Event Counting Applications to the STP268
(Shown for Clock Input 0 and External Gate 0)
Signal
Source
Digital Ground
Figure 38: Connecting Event Counting Applications to the STP268
(Shown for Clock Input 0 without an External Gate)
User Clock Input 0
Digital Ground
Gate 0
Digital Ground
clock edges are counted while the gate is active.
User Clock Input 0
Note that the signals shown for the STP268 screw
terminal panel correspond to connector J1.
STP268 Panel
TB54
TB56
TB57
STP268 Panel
TB54
TB57
