SC Port

The SC port on the 3C905B-FX NIC provides a 100 Mbps
fiber-based connection only.
The following table shows the cable requirements and
maximum network cable lengths for the SC port.
Port
SC
To connect the SC port:
1 Remove the protective cover from the NIC's
SC connector.
2 Connect the network cable to the SC connector on
the NIC.
3 Connect the other end of the cable to an active
100BASE-FX Fast Ethernet network port.
The next step is to install the network driver.
Go to
Chapter
Connecting the NIC to the Network
Cable Required
Long-wavelength
fiber-optic (1300 nm):
50 µ/125 µ
multimode fiber
62.5 µ/125 µ
multimode fiber
N K
1 0 0 L
A C T
1 0 0
Chapter 3, "Installing NIC Software in
4, "Installing the NetWare Client and Server
Maximum Network
Cable Length
Full-duplex: 2,000 m (6,560 ft )
Half-duplex: 412 m (1,351 ft)
Full-duplex: 2,000 m (6,560 ft )
Half-duplex: 412 m (1,351 ft)
Windows," or
33
Drivers."
