BNC Port

The BNC port provides a 10 Mbps connection only.
The following table shows the cable requirement and
maximum network cable length for the BNC port.
Port
BNC
To connect the BNC port:
1 Connect the BNC connector on the thin Ethernet cable
to the BNC port on the NIC.
2 Connect the other end of the network cable to
another PC or to a 50-ohm terminator.
If your PC is the last physical device in the network daisy
chain, you must connect a 50-ohm terminator to the
other end of the BNC T-connector.
The next step is to install the network driver.
Go to
or Chapter
Server
Connecting the NIC to the Network
Cable Required
10BASE2 thin Ethernet
coaxial (10 Mbps only)
Chapter 3, "Installing NIC Software in
4, "Installing the NetWare Client and
Drivers."
Maximum Network
Cable Length
185 m (607 ft)
Windows,"
31
