[Relay Group]; [Eci Group] - ADTEK MW-5 Operating Manual

Flock 0042h
mVavg
0043h
0044h
Reserved

[Relay Group]

Name Address
rYsb 0045h
rYsd 0046h
ry!md
0047h
ry!hy 0048h
ry!rd 0049h
ry!fd 004Ah
Name Address
ry@md
004Bh
ry@hy 004Ch
ry@rd 004Dh
ry@fd 004Eh
rYrst 004Fh
bank 0050h
(Option)
Reserved 0051h
Reserved 0052h

[ECI Group]

Name Address
ecI1
0053h
ecI2 0054h
34 / 36
0~3
Function Lock
0: none( none)
2: Engineer Level(
1~10 Moving average
Range
0000~9999
Start Band of input for relay energized
0000~5999
Start Delay Time of input 1 for relay energized
(0.1second)
0~5 Relay 1 Energized Mode
0: off(no use);
1: lo(Low Energized);
2: hi(High Energized)
3: lo hold(Low Energized Hold)
4: hi hold (High Energized Hold)
5: do(Digital Output)
0000~5000
Hysteresis of Relay 1
0000~5999
Energized Delay Time of Relay 1
(0.1second)
0000~5999
De-Energized Delay Time of Relay 1
(0.1second)
Range
0~5 Relay 2 Energized Mode
0: off(no use);
1: lo(Low Energized);
2: hi(High Energized)
3: lo hold(Low Energized Hold)
4: hi hold (High Energized Hold)
5: do(Digital Output)
0000~5000
Hysteresis of Relay 2
0000~5999
Energized Delay Time of Relay 2
(0.1second)
0000~5999
De-Energized Delay Time of Relay 2
(0.1second)
0~1 Reset for Relay Energized Latch
0: No(
0~3 Select the Banks of storage
bit0=1; Bank1 selected
bit1=1; Bank2 selected
bit2=1; Bank3 selected
bit0=bit1-bit2=0; Bank0 selected
Range
External Control Input 1
0~6
0: none (None);
1: reLpv(Relative PV for Power);
2: pVhld(PV Hold for Power);
3: Mrst (Reset for Maximum & Minimum);
4: rYrst (Reset for Relay Latch);
5: di (Digital Input);
6: (Option) bKsel(Bank selection)
External Control Input 2
0~6
0: none (None);
MW-5 Operating Manual 2012-07-19
1: User Level( user)
eng) 3: All(
Explain
Explain
no) 1: Yes( yes)
Explain
00h R/W
all)
1 R/W
Initial Write/Read Note
0 R/W
0 R/W
2 R/W
0 R/W
0 R/W
0 R/W
Initial Write/Read Note
1 R/W
0 R/W
0 R/W
0 R/W
0 R/W
00h R/W
R
R
Initial Write/Read Note
1 R/W
2 R/W
