lOcut: Low Cut for the Active power
If the setting value is positive, it means
the PV is in the range of absolute value
will be 0;
PV≤ I Setting value I, the display will be 0.
If the setting value is negative, it
expressed the PV will be X which it's
under the setting value;
PV< Setting value, the display will be
X(Setting value).
avg: Average update for the Active
power
05
Jittery Display caused by the noise or
unstable signal. User can set number to
99
average the readings to get smoothly
display.
The meter's sampling is 15 cycles/sec. If
the [avg](Average) set to be the
which means the meter is sampling 3
readings, and calculating the average to
update display once. At meantime, the
display update will be 5 times/sec.
mVavg: Moving Average update for the
Active power
01
Jittery Display caused by the reasons as
like as noise or unstable signal. User can
10
set number to average the readings, and
get smoothly display.
The meter's sampling is 15 cycles/sec. If
the [mVavg] (Moving Average) set to be
the 3, which the first cycle will be
same as average function. In following
cycles, the function will get a new fourth
reading and throw away first reading which
the purpose of keeping the newest 3
reading, and calculating the average then
update display. At meantime, the display
updated will be 15 times/sec.
MW-5 Operating Manual 2012-07-19
Settable range: 0.00~100.00%
Shift Up Down
Low Cut set to be +0.50
PV according
Present
to input signal
Value
[ lOcut]
)50
0.50
-0.50
Low Cut is set for 0.50, if the PV is
from -0.50~+0.50, that display will be 0.
Low Cut set to be -0.10
Present PV according
to input signal
Value
[ lOcut]
-)10
-0.10
Low cut
function
Low Cut is set for -0.10, if the PV is
under (< = -0.10), that display will be -0.10.
Settable range:
1(no function)~99 times
Shift Up Down
3,
Settable range:
0(no function)/1~10 times;
Shift Up Down
Enter
Low cut
function
Enter
