Installation
Installation
G8-TEL
G8-TEL for the Intercom Server GE 800:
available slot positions: 1 – 14
Connection Board G8A-TEL
For installation the connection board G8A-TEL has to be used (in extent of supply).
G8A-TEL
G3-TEL
G3-TEL for the Intercom Server GE 300:
available slot positions: 1 – 10
8
Connection Telephone line
A
B
NC NC
NC
NC
NC = not connected
Status-LEDs:
Run Line
Connection Telephone line:
NC NC
NC = not connected
G8-TEL, G3-TEL
A B
NC
NC
1.0/0609
