Commend C-G8-TEL Product Manual page 16

Auto Dialler Mode
Activation Dialling Sequence
The different dialling sequences are activated by inputs, to which e.g. a time switch can be connected.
For the inputs, dialling simulation has to be configured with the following code:
XX9T99 and the number of the dialling sequence,
e.g. XX9T992 → for activation of dialling sequence 2
Note:
The prefix "XX" cancels an existing conversation (built up by dialling the interface call number) before
switching the dialling sequence, otherwise the sequence would not be changed.
"XX" has no effect on an existing call request, i.e. the call remains.
Select Inputs – Dial via Input – Input initiates dialling:
Right click on the desired input and select the function Add input initiates dialling.
Select the input in the tree structure in the folder Input initiates dialling.
In the combo-boxes Subscriber 1 select the telephone interface, for which the switch-over of the
dialling sequence shall be carried out.
At Initiates dialling enter the respective code in the combo-box Dial / Key next to the desired input
level (e.g. "Short").
In the example above (screenshot) one input triggers the switch-over of the dialling sequences
1 and 2 for the telephone interface with call no. "113":
Level input: Break → dialling sequence 1 is active
Level input: Short → dialling sequence 2 is active
Attention:
Please make sure, that two inputs can not dial a code at the same time. This could happen e.g. if codes
for "short" and for "open" are configured for several inputs. If one input closes and the other opens at
the same time, it can not be guaranteed, if the "open"- code or the "short"- code is dialled first – always
the code dialled last becomes effective.
Group Call Types
This feature is available only, if the telephone interface is configured as "central control desk" (at
"Subscriber" – "Control Desks", see current version of the manual "PRO 800")!
The 16 call types of the Intercom Server can be grouped in 4 different call types – these 4 call types are
also used for "Individual
16
Messages".
