Commend CD 800 Operating Instructions

Important precautions
Keep this description in safe custody.
The availability of the features are dependent on the server
configuration and the feature level licence.
1. Range of application:
– As Intercom station of an Intercom Server.
2. Attention:
– Never insert objects of any kind through loudspeaker or
microphone holes.
– The Intercom station may be opened by authorised service
engineers only.
– This product must be disposed of pursuant the valid legal
provisions and separated from domestic waste.
3. Cleaning:
– For cleaning the Intercom station, a soft, lint-free cloth is
recommended.
– Never use strong solvents, abrasive cleaners or compressed
air for cleaning.
4. Connection:
– Connect the Intercom station to designated sockets only.
Call
1. Dial desired call number or select subscriber in subscriber list
(see "Display functions" , section "Subscribers").
2. Talk after dial tone.
3. End call with .
x
• During a call, the call number and the subscriber's name of the
conversation partner are displayed, in addition, the multifunction
LED lights.
Manual control of speech direction
Noisy environments may require a manual control of the speech
direction ("simplex"):
• Press to talk.
t
• Release to listen.
t
• End manual control of speech direction with .
77
Called subscriber busy
When the called subscriber is busy, there are three options:
• Wait for automatic re-call (switch busy tone off with
0
• Intrude with (keep pressed while talking).
t t
• Leave re-call request with .
5
• Leave call reminder with .
4
Minute tone
• Single minute tone: running call.
• Double minute tone: another call is waiting.
• Triple minute tone: conversation time expires in a few seconds
(extent conversation time with ).
77
Inquiry
1. Interrupt conversation with (tone signal sounds).
0
2. Dial desired call number (talk after dial tone).
3. Start another inquiry with and dial desired call number (talk
x
after dial tone). Otherwise, return to waiting subscriber with
.
xx
Transfer
1. Interrupt conversation with (tone signal sounds).
0
2. Dial desired call number (talk after dial tone).
3. Transfer subscriber to waiting subscriber with .
0
Microphone mute
1. Interrupt conversation with (waiting subscriber receives
7
privacy tone signal and multifunction LED blinks).
2. Resume conversation with .
7
All Call/group call with answer
It is possible to initiate an All Call or a group call:
1. Initiate All Call with or, depending on configuration,
00
group call with to .
010 019
2. End announcement with and wait for answer. Otherwise,
t
end announcement with without waiting for answer.
x
It is possible to respond to an All Call or a group call:
• Respond to All Call or group call with
tt
Secretary transfer
1. Activate transfer with and call number of secretary's
02
Intercom station (acknowledgement tone sounds).
2. Deactivate transfer with (continuous tone sounds).
030
Door opener
• Open door with during conversation.
1
Conference
1. Invite further participants with during conversation.
8
2. Dial desired call number (talk after dial tone).
3. Repeat steps "1. " and "2. " for each participant.
4. Start conference with .
8t
5. Talk with .
t
6. End conference with .
x
Privacy
1. Activate privacy mode with (acknowledgement tone
031
sounds).
2. Accept call with any button.
3. Deactivate privacy mode with
030
Reconnect last call
).
• Reconnect last call with (talk after dial tone).
0t
Background music
1. Switch on background music with
4t1
(depending on configuration).
2. Switch off background music with
4t0
Volume
• Adjust volume with arrow buttons during call (see also "Display
functions" , section "Volume").
Tone signals
• Dial tone: Anrufton
• Busy tone: B esetzt ton
Diskret ton
• Privacy tone:
• Error tone: Fehler
Quittierungston
• Acknow ledgement
tone: Zeit
1 sek
1 sec.
NOTE: Standard configuration
The button sequences described in this document are set as
factory default and can be changed individually. For further
information, see manual "PRO 800 Basic" .
.
(continuous tone sounds).
to
4t40
Operating instructions
.
Control desk solution CD 800
2 sek 3 sek
2 sec. 3 sec.
