MAINTENANCE
MAINTAINING THE RAMMER
Pull the bolt pin upwards so that it disengages the rammer assembly, allowing
1
the bolt to be removed via the rear of the ETEK5
2
Using a 3/16" hex key, unscrew and remove the rammer cap at the rear of the
(see figure 26B).
ETEK5
Raise the front of the ETEK5 and tap the ETEK5 onto your hand until the rammer
falls into the palm of your hand (see figure
Thoroughly clean the rammer shaft and all of its o-rings, replacing any o-rings
which appear damaged or worn (labelled
seals on the rammer shaft using Eclipse gun oil, do not use grease on the
rammer as this may cause adverse performance effects.
Replace any worn seals/bumpers using authentic ETEK5 spare parts.
DO NOT use Eclipse Grease on the rammer. Only use light paintgun oil, we
recommend Eclipse Oil.
The number of o-rings on the rammer may vary according to the model of ETEK5
that you have.
(see figure 26A).
26C).
figure 26D). Lubricate all of the
A
2 1
FIG 26B
A A A
A
FIG 26A
FIG 26C
FIG 26D
