USING THE ETEK5

ATTACHING A LOADER

Release the clamping lever on the feed neck
if your loader can easily be pushed into the top of the feed neck. If the loader
cannot easily be pushed into the feed neck, loosen the top screw on the feed
neck by turning it counter-clockwise using a 5/32" hex key
When you have managed to push your loader into the feed neck, close the
clamping lever to secure it firmly in place
then you will need to release the clamping lever, tighten the top screw slightly
by turning it clockwise with a 5/32" hex key
clamping lever. Repeat this process as necessary to secure your loader in place
You have now attached a loader to your ETEK5. Once you have filled your loader
and air tank you will then be ready to begin using your ETEK5.
WARNING!
Do not over tighten the Clamping Feed Neck as this may damage the
loader or feed neck itself.
(see figure 13A) and test to see
(see figure 13B).
(see figure 13C). If the loader is loose
(see figure 13B), then close the
FIG 13A
FIG 13B
WARNING
FIG 13C
