USING THE ETEK5

THE ETEK5 NAVIGATION CONSOLE

The ETEK5 utilises a coloured LED (labelled
information that the user requires.
The console looks slightly different if you have upgraded to the ETEK5 OLED board
(see figure 9B). The LED colour information is further supported by the OLED display
(labelled figure 9B).
C
The various functions of both the Select button
LED are outlined below.
The select button is used to:
Switch the ETEK5 on and off.
•
Switch the BS (eye system) on and off.
•
To scroll through parameters and edit parameters.
•
The LED on the navigation console is used to:
Display the status of the BS (eye system).
•
Display the value of a parameter.
•
Display the status of the battery.
•
Display power up and power down status.
•
Display tournament lock status.
•
Display that factory settings have been restored.
•
To confirm whether a parameter value has been accepted or rejected.
•
Please note: the information displayed on the LED is different when the ETEK5 OLED
board is installed.
14 ETEK5 MANUAL
figure 9A) to display all of the
A
(labelled figure 9A) and the
B
STANDARD CONSOLE OLED DISPLAY
A
B
FIG 9A FIG 9B
WARNING!
De-gas your marker, discharging any stored gas in a safe
direction, and remove the barrel, loader, air system and any
paintballs to make the marker easier and safer to work on.
C
WARN
