USING THE ETEK5

THE ETEK5 CIRCUIT BOARD

The ETEK5 circuit board sits within the frame and is accessible by removing the
rubber grips (see page 29 to learn more).
There are three sockets on the ETEK5 circuit board
solenoid connector , the BS connector
A
There is also a tournament lock button
Information on the tournament lock button functionality can be found on page 24.
1 When the ETEK5 is turned on, the Breech Sensor is automatically enabled.
2 The colours displayed during the power up sequence may vary depending on the region the marker
was originally purchased.
10 ETEK5 MANUAL
(see figure 5A), the ETEK5
and the micro-switch connector
B
and the OLED board connector
D E
.
C
.
FIG 5A
A
B
C
D
E
