ADVANCED SET-UP

THE SET-UP MODE

To enter the set-up mode, fully depress and hold the trigger and then switch on
the ETEK5. The LED should flash white. Release the trigger.
If the LED flashes red then the tournament lock is on. The set-up mode can only
be accessed if the tournament lock is off (see page 24).
Once in set-up-mode, each parameter is represented by a different colour on
the LED. Press and release the trigger to cycle through all of the parameters.
COLOUR PARAMETER
Red Preset
Maximum ROF with BS on
Green
(capped modes only)
Blue Maximum ROF with BS off
Purple Dwell
Light Blue Debounce
To see the value of the selected parameter, push and quickly release the select
button . The value will be indicated in units (long flashes) and then tenths
(short flashes) on the LED display in the colour of the selected parameter.
E.g. A Dwell of 14.5ms would be indicated as follows:
14 long flashes of the purple LED
•
5 short flashes of the purple LED
•
A zero is indicated by no flashes. E.g. A Dwell of 11.0ms would be indicated
as follows:
11 long flashes of the purple LED
•
0 short flashes of the purple LED
•
26 ETEK5 MANUAL
In-depth information on
setting up the ETEK5.

MODIFYING A PARAMETER

You can modify a parameter as follows.
Ensure that you are in set-up mode.
1
Choose the parameter that you wish to modify by repeatedly pressing the
2
trigger until the LED turns to the parameter colour.
Push and hold the select button
3
Set the units value by pulling the trigger once for each unit, the LED will
4
flash with each trigger pull.
RANGE
Push and release the
5
1 to 4
Set the tenths value by pulling the trigger once for each unit, the LED will
6
4.0 to 15.0 BPS
flash with each trigger pull. DO NOT pull the trigger if the required digit is
zero
1
4.0 to 15.0 BPS
Push and release the
7
8.0ms to 16.0ms
is green then the value has been accepted and saved. If the colour is red
1 to 10
then the value has been rejected and remains unchanged.
For example to set a parameter to 14.5 when following the steps above:
Pull the Trigger 14 times when at step 4 then press
•
Pull the Trigger 5 times when at step 6 then press
•
To leave a parameter unchanged having already started to modify it, do not pull
the trigger for 5 seconds and the value will be rejected.
Exiting Set-up mode
To exit set-up mode, push and hold the
Then release the
start flashing, displaying the current BS status.
1 If the parameter does not support tenths then these steps are skipped.
for 1 second. The LED will go off.
button to switch to the tenths value
.
button. The LED will flash three times. If the colour
button until the LED turns blue.
button, the ETEK5 will exit set-up mode and the LED will
.
1
