MAINTENANCE
THE SL4 INLINE REGULATOR ASSEMBLY
Disconnect the macroline for the inline regulator. See page 16 for more info on
removing the macroline.
Peel the bottom of the regulator sleeve over the inline regulator bottom and swivel
(see figure 22A). Unscrew and remove the inline regulator bottom, then remove
the swivel (see figure 22B). Gripping the regulator sleeve firmly at the top, pull the
sleeve down and off the marker (see figure
unscrew the inline regulator from the ETEK5
Inspect the o-ring at the top of the threads on the FRM for damage
figure 22E). Replace and re-lubricate as necessary.
Tip both the piston and spring out of the top of the inline regulator
Insert a 1/8" hex key into the adjuster screw assembly in the bottom of the inline
regulator, turn the adjuster screw clockwise through the inline regulator body
(see figure 22G), and push the adjuster assembly out of the top of the inline regulator
body.
2
Thoroughly clean the 011 NBR70 o-rings that sits on the outside of the adjuster
assembly, then re-lubricate with Eclipse Grease
Using a dry cotton bud, clean the internal 008 NBR70 o-ring that sits inside the top
section of the adjuster top. Then using a small hex key gently apply Eclipse Grease
to the o-ring (see figure 22I).
1
1 If any o-rings are damaged then replace them. Extra o-rings are available in parts kits available at
www.planeteclipse.com.
2 The adjuster screw can only be removed by turning it upwards through the bottom section of the
inline regulator. The regulator will be damaged if the adjuster screw is removed incorrectly.
Always de-gas your marker, discharging any
WARNING! WARNING stored gas in a safe direction, and remove the
barrel, loader, air system and any paintballs to
make the marker easier and safer to work on.
22C). With the regulator sleeve removed,
(see figure 22D).
(labelled
A
1
(see figure 22F).
(labelled and in figure 22H).
A B
A
1
FIG 22A FIG 22B
FIG 22C FIG 22D
FIG 22E FIG 22F
FIG 22G FIG 22H
A
B
