Reversing deflector and operating hydraulics
Repair manual
Use thread locking compound.
3. Set the belt in its place and lift the bracket until the belt tightens.
4. Tighten the bracket fastening screws at the same time.
The tightening torque is 46 Nm.
5. Install the pressure hose (figure 72, point A) and return hose (figure 72,
point B).
6. Fill the oil reservoir with oil and use the system (motor running, in forward
gear), moving the reversing deflector up and down several times.
This removes air from the system.
4.3.4. Replacing the oil filter
The oil filter in the oil reservoir must be replaced after every 500 operating
hours.

Replacing the oil filter:

1. Open the six cover screws (figure 78)
Figure 78. Oil reservoir cover screws
The filter is located under the cover and has a spring on top of it that
keeps the filter in place (figure 79).
KM/285/EN/1.1.0 57
