Figure 31. Shaft sleeve
Removing the shaft sleeve:
Open the screw at the end of the shaft and pull the sleeve off the shaft.
2.2.3. Assembling the rear-end bearing
Assembly of the rear bearing:
1. Push the bearing into the bearing housing from the back (figure 32).
Use a bearing retaining compound to ensure that the bearing stays in
place (such as Loctite 648 or similar).
22
Main shaft and bearing
Repair manual
KM/285/EN/1.1.0
