GC2e Wireless Security System | Installation and Programming Guide

Final Installation Setup

Exiting Programming (System Configuration)

After programming the Control Panel, all the changes need to be
saved in memory. After saving, the programmed settings will remain
in memory, even after a total power loss.
After setting all the required programming values for the
1.
sensors and the Control Panel, tap End .
Review the Summary of System Configuration screen . Use the
2.
↓ and ↑ arrows to scroll through the listing. Verify that each
option is set correctly.
Figure 51
Summary of System Configuration Screen
To save the programming changes, be sure the Save
3.
Changes option is checked. To exit without saving
programming changes un-check the Save Changes
option (for verification, an additional confirmation
screen appears) . Tap Exit .
The Control Panel takes a few seconds to restart and
4.
display the Home screen .
Customizing the Installation
After programming the Control Panel, go to the User Toolbox
and customize the system to suit the installation. To access
the User Toolbox, do the following:
From the Home screen, tap Security .
1.
From the Security screen, tap, Menu .
2.
From the Menu screen, tap Toolbox .
3.
Enter the master user code (the default master user
4.
code is 1111) .
Tap User Management .
5.
To add, change, or delete a user code, tap a User #
6.
button. The system asks to confirm the code entered. Be
sure to set a Duress Code as User #8 .
Figure 52
User Management Screen
NOTE: User codes 0000, 0001, and the Installer Code are not
permitted.
Setup each user code with the User Access Option screen.
7.
Each User Code can be set to be currently valid or not, or to
have conditional validity. Refer to the User Guide for details
on setting User Code Access Schedules. When done, tap
Back .
At the Toolbox (1 of 3) screen, tap Brightness/Volume .
8.
Then set the brightness level for the display screen and the
volume for the chime & voice . When done, tap OK .
Figure 53
Brightness/Volume Screen
At the Toolbox (1 of 3) screen, tap → to go to the Toolbox
9.
(2 of 3) screen .
Tap Backlight Timeout. Then tap the button that
10.
corresponds to the number of seconds or minutes the
backlight turns OFF after it is idle. When done, tap OK.
Figure 54 Back Light Timeout Screen
NOTE: If the LTE (Cellular) Radio Module is properly installed
and registered, the system automatically sets the date and time
for you . Use the following steps only if you want to change the
date and time.
Copyright © 2018 Nortek Security & Control
59
