GC2e Wireless Security System | Installation and Programming Guide
Q16: Police Emergency Key (0-2)
DEFAULT: (1) Audible
The Control Panel's panic emergency button action can be
programmed. The panic emergency button is displayed by
pressing the
button.
•
The default (1) Audible allows the panic emergency
button to sound an audible alarm.
•
For silent activation, select (2) Silent Panic .
•
To not display the panic emergency button, select (0)
Disabled .
NOTE: Setting this programming question for (2) Silent
Panic makes the Police button on all RF keypads silent also.
Q17: Fire Emergency Key (0-1)
DEFAULT: (1) Audible
The Control Panel's fire emergency button can be enabled
or disabled. The fire emergency button is displayed by
pressing the Control Panel's button.
•
The default setting (1) Audible allows the fire
emergency button to sound an audible alarm.
•
To disable and not display the fire emergency button,
select (0) Disabled .
Q18: Emergency Key (0-1)
DEFAULT: (1) Audible
The Control Panel's emergency button can be enabled or
disabled. The panel's emergency button is displayed by
pressing the Emergency
•
The default setting (1) Audible sounds an audible
alarm when the button is pressed.
To disable this button, select (0) Disabled .
NOTE: If all three (3) Emergency buttons are disabled, the
Control Panel displays a message when its Emergency
button is pressed.
Q19: Quick Arming (0-1)
DEFAULT: (1) Enabled
Quick arming allows the subscriber to arm the system
without having to enter a user code . If Open/Close Reports
are being sent, quick arming is reported as User 0 .
•
The default (1) Enabled allows quick arming .
•
To turn off quick arming, select (0) Disabled .
Q20: Swinger Shutdown Count (1-6)
DEFAULT: (2) Two Trips
The minimum setting of (2) Two Trips is required for ANSI/
SIA CP‐01 compliance. This default setting can be increased
to three or more trips without affecting ANSI/SIA CP‐01
compliance .
An unwanted series of multiple faults (usually caused by
a bad contact or sensor) is called a "swinger". Swinger
shutdown sets the maximum number of alarms that any
sensor or hardwire loop can trigger during a single arming
period .
NOTE: CO and Smoke detector alarms are not limited by
the swinger shutdown count. Other types of 24-hour zones
are limited by the swinger shutdown count .
The default setting (2) Two‐Trips sets the swinger
•
shutdown count at two (2) trips .
•
To change this count, select (1-6).
button on the panel.
Q21: Siren Supervision Time (0-3)
DEFAULT: (0) Disabled
The wiring connection to the external sounder can be
supervised. If the wiring to the sounder is cut for 15, 30, or 45
seconds, a bell trouble report can be sent to the Central Station.
•
The default setting (0) Disabled turns external sounder
supervision OFF .
•
To supervise the external sounder wiring, select:
•
(1) 15 Seconds
•
(2) 30 Seconds
•
(3) 45 Seconds
Q22: CS Lack of Usage Notification Time
(0-255)
DEFAULT: 7 days
If this system has not been armed for a specified number of
days, inactivity reports can be sent to the Central Station.
The default setting is 7 days .
•
•
To change the duration, select a value between 1 to 255
days .
•
To turn this feature OFF, select 0 days .
Q23: Radio Modem Network Failure Time
(0-255)
DEFAULT: 30 Minutes
NOTE: LTE (Cellular) Radio Module must be installed to use this
function.
If the optional LTE (Cellular) Radio Module loses its cellular
connection, specify the amount of down time that must pass
before triggering a trouble condition.
•
The default setting is 30 minutes .
•
To specify a different amount of time, enter a value
between one (1) to 255 minutes .
•
To turn this feature OFF, select 0 minutes .
NOTE: After cellular service is restored for five (5) minutes, the
trouble condition automatically clears.
Q24: Radio Modem Network Failure Causes
Trouble (0-1)
DEFAULT: (1) Enabled
NOTE: LTE (Cellular) Radio Module must be installed to use this
function.
Selects whether the Control Panel will sound and display trouble
if the optional LTE (Cellular) Radio Module has lost its cellular
connection. The trouble sounder can be silenced by the user at
the Control Panel (cell radio trouble is logged regardless of this
setting). When the cellular radio module connection is restored,
the trouble indications automatically clear.
•
The default (1) Enabled allows radio module failure trouble
indications.
•
To turn off radio module failure trouble indications, select
(0) Disabled .
Copyright © 2018 Nortek Security & Control
Control Panel Programming
50
