Nortek Security & Control 2GIG e Series Installation And Programming Manual page 45

GC2e Wireless Security System | Installation and Programming Guide
Sensor Types (Zone)
(04) Interior Follower
(05) Day Zone
(06) 24-Hour Silent Alarm
(07) 24-Hour Audible Alarm
(08) 24-Hour Auxiliary Alarm
(09) 24-Hour Fire
(10) Interior with Delay
(14) 24-Hour Carbon Monoxide
Q: Select Wired Sensor# Equipment Type
DEFAULT: Varies by wired sensor type
NOTE: This question is only displayed when certain sensor types
(zones) are selected .
The equipment type selection will affect the sensor's extended
reporting code.
The following sensor types require equipment type selection:
Sensor Type (Zone)
(04) Interior Follower
(06) 24-Hour Silent Alarm
(07) 24-hour Audible Alarm
(08) 24-Hour Auxiliary
(10) Interior with Delay
(23) No Response Type
Select the equipment type that matches the sensor equipment using
the ← or → arrows, or enter the equipment type number directly on
the keypad .
NOTE: This Control Panel does not provide auxiliary accessory output
power .
Connecting a hardwire PIR using equipment type "motion" will
require an external stand-alone battery backed-up power supply for
the PIR .
Q: Wired Sensor # Equipment Code (0-9999)
DEFAULT: (0 )
Select the four (4)-digit equipment code that corresponds to the
appropriate sensor model . See "Equipment Codes" on page
Q: Select Wired Sensor# Equipment Age (0 to 1)
DEFAULT: (0) New
The Control Panel can be used with new or existing wired sensors.
• If this wired sensor is new for the installation, leave the
default setting of (0) New .
• If this wired sensor is already installed, select (1) Existing .
RF Sensors Wired Sensors
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes No
Yes Yes
Yes No
Equipment Types
(1) Motion
(2) Contact
(1) Contact
(11) Emergency
(1) Contact
(11) Emergency
(1) Contact
(6) Freeze
(8) Water
(10) Temperature
(11) Emergency
(1) Motion
(2) Contact
(1) Contact
(2) Motion
37 .
Q: Select Wired Sensor# Normal State
DEFAULT: (0) Not Used
The two hardwired loops can be wired for normally open (N/O) or
normally closed (N/C) contacts, or for end-of-line (EOL) resistor.
• The default setting (0) Not Used disables this wired sensor .
• To use this wired sensor, select the way the loop is wired:
Wired Sensor Normal State
• (0) Not Used
• (1) Closed
• (2) Open
• (3) End‐of‐Line Resistor
Q: Select Wired Sensor# Dialer Delay (0 to 1)
DEFAULT: (1) Enabled
If this feature is enabled, the delay time must be set to a minimum of
30 seconds for ANSI/SIA compliance. To set the delay time, see
Abort Window Dialer Delay (0-2)" on page
Wired sensors can trigger the digital communicator immediately or
after a delay.
• The default setting (1) Enabled causes delayed dialing for this
wired sensor number .
• For immediate dialing for this wired sensor number, select (0)
Disabled.
Q: Construct Wired Sensor # Voice Descriptor
DEFAULT: No Default
NOTE: For a list of voice descriptors, see
page 35 .
The voice descriptors are the words the Control Panel will announce
for this wired sensor if this wired sensor is programmed for voice
annunciation. Up to five (5) words are allowed.
Tap Insert to place a word from the vocabulary into the data
1.
entry field.
Use the ← or → arrows to scroll through the words, or enter the
2.
word's three (3)-digit number.
Tap Insert again for the next word. Up to five (5) words are
3.
allowed .
To move between words, tap the Fwd and Back buttons.
4.
To remove a word, tap Delete .
5.
Q: Select Wired Sensor# Reports (0 to 1)
DEFAULT: (1) Enabled
Wired sensors can be programmed to trigger a report to the Central
Station or not.
• The default setting (1) Enabled activates reporting for this wired
sensor number .
• To prevent reporting for this wired sensor number, select (0)
Disabled .
Q: Select Wired Sensor# Chime (00 to 13)
DEFAULT: (0) Disabled
Each wired sensor can be set to sound a "ding-dong" chime and/or
sound its voice descriptor when the sensor is triggered .
• The default setting (0) Disabled inactivates the chime for this
wired sensor .
• If a chime and/or voice is required for this wired sensor,
choose one of the other chime options (next page):
