GC2e Wireless Security System | Installation and Programming Guide
Programming Navigation
When the installer is using the System Configuration menus,
the Control Panel will present each programming question
sequentially. Most programming questions have a single
numeric value response or a simple enabled/ disabled selection.
Some programming questions have sub- options that can be set.
These sub-options are displayed for the question selected and
can be accessed through navigation keys on the display.
Navigation Arrows & Go To Button
The programming question screens display up, down, left, and
right navigation arrows. Use these arrows to scroll through the
programming questions and to select sub- options.
Tap the Go To button and then enter a two (2)-digit code to
jump directly to a programming question. See
Question Table" on page
when waiting for you to enter a question number. Tap Cancel to
back out .
Figure 38
Navigation Arrows & Go To Button
Questions without Sub-Options
Most of the programming questions do not have sub- options.
They navigate as follows. Questions without sub- options do
not display a Skip button.
Figure 39
Questions without Sub-options
•
The ↑ and ↓ arrows select the next or previous
programming question.
•
The ← and → arrows choose values for the question
on or move the cursor left and right along the white
data entry field.
Questions with Sub-Options
Some of the programming questions have sub-options.
They navigate as follows. Questions with sub-options
display a Skip button during the question. The Skip button
advances to the next programming question/section.
"Programming
28 . The Go To button changes to Cancel
•
The ↑ and ↓ arrows select the next or previous
programming sub-question.
•
The ← and → arrows choose values for the question on
or move the cursor left and right along the white data
entry field.
Figure 40
Questions with Sub-options
Questions with Data Entry
Some of the programming questions require entering
numeric or alphabetic data. For devices that can be named,
the Control Panel contains a large vocabulary with words to
choose from . See
"Voice Descriptors" on page
•
Tap Insert to display the first word in the Voice
Descriptors list. Use the ← and → arrows to scroll
through the word list, or enter the corresponding three
(3)-digit code. See
"Voice Descriptors" on page
•
Tap Backspace to move the cursor to the left and delete
one (1) character at a time.
•
Tap Delete to delete one character to the right of the
cursor or any characters that are highlighted .
•
Tap Forward to highlight the next word in a multi- word
data field.
•
Tap Back to highlight the previous word in a multi- word
data field. The Back button displays the previous screen
in some cases .
•
Tap Shift to reveal alternate characters on the keypad
that can be used for data entry .
Figure 41
Questions with Data Entry
Copyright © 2018 Nortek Security & Control
35 .
35 .
26
