GC2e Wireless Security System | Installation and Programming Guide
Q: Enter Fob # Serial Number (7 Digits)
DEFAULT: 0000000
Key fob serial numbers can be manually entered or learned from
the fob .
• For manual entry, enter the fob number that was logged for
the fob being programmed . Use the Shift button to access
alpha characters .
• For automatic entry, tap Shift, then tap Learn . The Control
Panel will wait for a fob transmission . Trigger the fob being
programmed and the Control Panel will learn the fob's serial
number .
Q: Select Fob # Equipment Age (0 to 1)
DEFAULT: (0) New
The Control Panel can be used with new or existing key fobs.
• If this fob is new for the installation, leave the default
setting of (0) New .
• If this fob is already installed, select (1) Existing .
Q: Select Fob # Emergency Key (0 to 4)
DEFAULT: (0) Disabled
Pressing the and buttons on a key fob at the same time for
5 seconds can trigger an emergency alarm .
• The default setting (0) Disabled inactivates the emergency
function the fob #.
• To enable the emergency function for this fob, select one (1)
of the four (4) options:
• (0) Disabled
• (1) Auxiliary Alarm
• (2) Audible Alarm
• (3) Silent Panic
• (4) Fire
Q: Select Fob# Key # Can Disarm (0 to 1)
DEFAULT: (1) Enabled
As an installer, consult the user as to whether to set the key
fob to allow disarming the Control Panel with the key fob's
buttons. If the user wants the key fob used as a stationary wall
fob, it can also be set to prevent using the key fob to disarm the
system .
• The default setting (1) Enabled allows the fob to disarm the
system .
• To not allow the fob to disarm the system, select (0)
Disabled .
Q: Construct Fob# Voice Descriptor
DEFAULT: (#) Keyfob
The voice descriptor are the actual the words that the Control
Panel use for this fob for low battery announcements and log
entries. Up to five (5) words are allowed.
Tap Insert to place a word from the vocabulary into the data
1.
entry field.
Use the ← or → arrows to scroll through the words, or enter
2.
the word's three (3)-digit index number.
Tap Insert again for the next word. Up to five words are
3.
allowed .
To remove a word, tap Delete .
4.
Q: Select Fob (#) Arm No Delay (0 to 1)
DEFAULT: (0) Disabled
Key fobs can be set to arm the Control Panel with or without an
entry delay .
• The default setting (0) Disabled sets this fob to arm the
system with an entry delay .
• To set this fob to arm the system without an entry delay,
select (1) Enabled .

Wireless (RF) Keypad Programming

The Control Panel can be programmed with up to four (4) RF
keypads or RF touch screen keypads .
NOTE: RF Keypads 1 - 4 report to the Control Panel as sensors 59
- 62 (for emergency, and low battery reports).
RF Keypad Reporting Codes
Keypad 1 Reports as sensor #59
Keypad 2 Reports as sensor #60
Keypad 3 Reports as sensor #61
Keypad 4 Reports as sensor #62
• User Codes #1 - #8 are reported for openings and closings
• User Code #0 is reported for Quick Arming The following
options can be set for each RF keypad:
• Select RF Keypad Number. Select keypad number 1-4.
• Select RF Keypad # Used . Enable or disable the keypad .
• Select RF Keypad # Equipment Code . Select the
equipment code for the keypad . See
on page 37 .
• Select RF Keypad # Other Equipment Code . If you
selected (0000) Other, enter the special equipment code .
• Select RF Keypad # Serial # . Enter the serial number from
the keypad or "learn" by sending a signal.
• Select RF Keypad # Equipment Age . Select (0) New or (1)
Existing .
• Select RF Keypad # Emergency Keys . Select (1) Enabled or
(0) Disabled .
• Construct RF Keypad # Voice Descriptor . Construct the
name assigned for the keypad announcement . See
Descriptors" on page 35 .
Copyright © 2018 Nortek Security & Control
Installer Programming
"Equipment Codes"
"Voice
46
