GC2e Wireless Security System | Installation and Programming Guide
Control Panel Features
External Features
Figure 2
Control Panel External Features
A
C
A
Alarm Sounder and Speaker
B
Color Display with Touchscreen
C
Emergency Button/Indicator
D
Microphone
E
Home Button/Indicator
Sounds all system local alarms, voice prompts, system sounds, and audio for two (2)-way voice
communications with the Central Station
Shows all system information, status, programming, and functions as the keypad.
Display cycles clock, calendar, and weather with an Alarm.com account (tap manually to change)
Lights WHITE when enabled for emergency alarms and flashes during emergency alarms
For voice communication with the Central Station
Sensor Status
Lights BLUE when all sensors are closed (ready to arm)
Not lit when any sensor is open (not ready to arm)
Arming Status
Lights RED when system is armed
Flashes RED during the Entry Delay
Alarm Memory
Flashes RED during an alarm
Flashes RED after an alarm while system is still armed
Power Outage
Flashes WHITE during power outage (system on battery backup)
Flashes BLUE when all sensors are closed (ready to arm)
Flashes ORANGE when any sensor is open (not ready to arm)
Flashes RED while system is armed
E
Copyright © 2018 Nortek Security & Control
B
D
8
