2 Operating the ITC8xxx

Before switching on the laser current please refer to chapter 1.5, "Presettings" on
page 13
With modules of the ITC8xxx series all settings are executed at once. It is

2.1 Functions in the main menu

2.1.1 Display

The main menu shows the channel number and the two most important operating
parameters of the ITC8xxx module.
channel no.
In constant current mode the first parameter is the laser current I
the second value is the temperature T in °C.
In constant power mode the first parameter is the optical power P
second value is the temperature T in °C.
If the LD and TEC controllers are switched off, the set values (I
displayed. If one or both controllers are turned on the corresponding actual values
appear (I /P /T ).
LD LD A
