54 Commands
_________________________________________________________________________________

3.2.20 Programming the PID shares (SHAREP, -I, -D)

Programming:
":SHAREP:SET <NR3>"
":SHAREI:SET <NR3>"
":SHARED:SET <NR3>"
Reading:
":SHAREP:SET?"
":SHAREI:SET?"
":SHARED:SET?"
":SHAREP:MIN?"
":SHAREI:MIN?"
":SHARED:MIN?"
":SHAREP:MAX?"
":SHAREI:MAX?"
":SHARED:MAX?"
(Refer to chapter 1.7.2, "PID adjustment" on page 25)

3.2.21 Switching the TEC on and off (TEC)

Programming:
":TEC ON"
":TEC OFF"
Reading:
":TEC?"
______________________________________________________________________________________________________
Programs the P-share
Programs the I-share
Programs the D-share
Reads the P-share
[:SHAREP:SET <NR3><LF>]
Reads the I-share
[:SHAREI:SET <NR3><LF>]
Reads the D-share
[:SHARED:SET <NR3><LF>]
Reads the minimum allowed P-share
[:SHAREP:MIN <NR3><LF>]
Reads the minimum allowed I-share
[:SHAREI:MIN <NR3><LF>]
Reads the minimum allowed D-share
[:SHARED:MIN <NR3><LF>]
Reads the maximum allowed P-share
[:SHAREP:MAX <NR3><LF>]
Reads the maximum allowed I-share
[:SHAREI:MAX <NR3><LF>]
Reads the maximum allowed D-share
[:SHARED:MAX <NR3><LF>]
Switch the TEC output on
Switch the TEC output off
Reads status of the output
[:TEC ON<LF>]
[:TEC OFF<LF>]
