":ILD:MEAS?"

3.2.6 Programming the monitor diode current (IMD)

Programming:
":IMD:SET <NR3>"
":IMD:START <NR3>"
":IMD:STOP <NR3>"
":IMD:MEAS <NR1>"
Reading:
":IMD:SET?"
":IMD:ACT?"
":IMD:MIN?"
":IMD:MAX?"
":IMD:MIN_W?"
":IMD:MAX_W?"
":IMD:MIN_R?"
":IMD:MAX_R?"
":IMD:START?"
_____________________________________________________________________________________________________
© 2010 Thorlabs
Reads the position of the laser diode current as
measurement value in the output string for "ELCH"
(1....8, 0 if not selected)
[:ILD:MEAS <NR1><LF>]
Programs the monitor diode set current
Programs the monitor diode start current for "ELCH"
Programs the monitor diode stop current for "ELCH"
Programs the monitor diode current to be measurement
value in the "ELCH" output string on position <NR1>
(1....8)
Reads the monitor diode set current
[:IMD:SET <NR3><LF>]
Reads the actual monitor diode current
[:IMD:ACT <NR3><LF>]
Reads minimum monitor diode set current allowed
[:IMD:MIN <NR3><LF>]
Reads maximum monitor diode set current allowed
[:IMD:MAX <NR3><LF>]
Reads minimum monitor diode current for
Ipd – DAC = 0000
[:IMD:MIN_W <NR3><LF>]
Reads maximum monitor diode current for
Ipd – DAC = FFFF
[:IMD:MAX_W <NR3><LF>]
Reads minimum monitor diode current for
Ipd –ADC = 0000
[:IMD:MIN_R <NR3><LF>]
Reads maximum monitor diode current for
Ipd –ADC = FFFF
[:IMD:MAX_R <NR3><LF>]
Reads the monitor diode start current for "ELCH"
[:IMD:START <NR3><LF>]
