1.6.7 Connecting an LM335

The IC-temperature sensor LM335 is connected between pin 10, pin 11 (+) and pin 8
(-).

1.6.8 Connecting the TEC element

Connect the TEC element to pins 5 and 6 (+) and the pins 13,14 and 15 for (-).
_____________________________________________________________________________________________________
© 2010 Thorlabs
10
11
LM 335
8
Figure 7 Connecting an LM335
5
6
+
-
13
14
15
Figure 8 Connecting a TEC element
