34 Functions in the channel menu
_________________________________________________________________________________

2.2.7 Selecting the type of the sensor

The sensor type can be chosen in the TED8xxx modules by selecting the line
"Thermistor" respectively "AD590".
AD590
Thermistor
Select the desired type and press

2.2.8 Calibrating a thermistor

2.2.8.1 Select the calculation method
If the relation between temperature and resistance for a given thermistor is known,
the PRO8 system is able to display temperature directly in °C instead of resistance in
Ω. Therefore, a calibration of the sensor in °C is necessary.
Two well known methods to calculate the resistance from temperature are
implemented:
•
The exponential method
•
The Steinhart-Hart method
In the channel menu you can choose between these two methods and enter the
corresponding parameters:
Select the line
Steinh.-Hart
resp.
Exponential
The right softkey toggles between the two methods.
Select the desired type and press
______________________________________________________________________________________________________
= AD590 and LM335 families
= Thermistor. The corresponding range has to be selected
.
to make setting valid.
