12

Operating elements at the front of the module

_________________________________________________________________________________
1.4 Operating elements at the front of the module
Connector for the
TEC element
Connector for the
laser diode
Potentiometer for I
LIM
Connector for both
laser diode and TEC
Figure 1
The ITC8xxx and ITC8xxxDS15 front panel
______________________________________________________________________________________________________
© 2010
Thorlabs
